KAWASAKI
JS300
1987
Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS300 1987 - Engine/Transmission - CARBURETOR
Engine/Transmission
CARBURETOR
No Part Part No Notes
223 SCREW-PAN-WS-CROS 223B0307
11009 GASKET 11009-3036
11009A GASKET 11009-3734
11009B WASHER FLOAT VLV SEAT 16029-004
11009C GASKET 92065-526
11009D WASHER 92065-528
11009E GASKET 11060-3704
11009F GASKET 11060-3705
11034 PLATE-CARB. SIDE 59086-541
13169 ARM 59001-506
13236 LEVER-COMP,CHOKE 13236-3701
13320 LEVER-ASSY,THROTTLE 13320-3701
14024 COVER,CARBURETOR 14024-3721
15001 CARBURETOR-ASSY 15001-3728
16009 NEEDLE-JET,PILOT SCRE 16009-2092
16009B SCREW,HIGH SPEED 16009-3002
16025A VALVE-THROTTLE,#140 16025-3702
16030A VALVE-FLOAT,#1.8 16030-3702
16126A VALVE,CHOKE 16126-3701
39074 LEVER-ASSY-THROTTLE,S 39074-3703
39074A LEVER-ASSY-THROTTLE,T 39074-3704
43028 DIAPHRAGM,PUMP 43028-3001
43028A DIAPHRAGM,PUMP 43028-3002
43028B DIAPHRAGM,PUMP 43028-3701
43028C DIAPHRAGM,CHECK SEAT 51069-501
43028D DIAPHRAGM,MAIN 51069-502
43049 PACKING 43049-3702
59336 BODY,DIAPHRAGM(2) 59336-3002
59336A BODY,DIAPHRAGM(3) 59336-3003
92009 SCREW,CHOKE VALVE 92009-3704
92009A SCREW,CHOKE LEVER 92009-3705
92009B SCREW 92009-3714
92009C SCREW 4X12 92011-510
92009D SCREW 4X30 92011-515
92015 NUT,THROTTLE LEVER 92015-3717
92022 WASHER,THROTTLE LEVER 92022-3722
92022A WASHER 92022-537
92027 COLLAR,THROTTLE SHAFT 92027-3709
92028 BUSH 92028-3730
92043 FLOAT PIN 16032-006
92055 "0" RING 92055-510
92055A "0" RING,DRAIN PLUG 92055-1093
92081 SPRING,CHOKE SHAFT 92081-3705
92081A SPRING 92081-528
92081B SPRING 92081-534
92144 SPRING 92144-3709
92144A SPRING 92144-3715
