KAWASAKI
JS550
1982
Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1982 - Engine/Transmission - CARBURETOR
Engine/Transmission
CARBURETOR
No Part Part No Notes
1 CARBURETOR 16001-3005-YR
2 SPRING,THROTTLE SHAFT 92081-547
3 BUSHING,THRTLE SHAFT 92028-514
4 CIRCLIP,5M/M,SUS304 92033-3004
5 THROTTLE SHAFT ASSY 16041-3001
6 SPRING,CABLE PULLY 16040-022
7 SCREW,4X20 92009-3009
8 BOLT,4X8 92001-3026
9 SPRING 92081-525
11 CIRCLIP,5M/M,SUS304 92033-3004
12 WASHER,PLAIN,6NYLON 92022-3020
13 TERMINAL,CHOKE SHAFT 21169-3008
14 SCREW-PAN-HEAD 3X6 220B0306
15 WASHER SPRING 3MM 461F0300
16 VALVE,THROTTLE 16025-503
17 SCREW 3X5 92011-517
18 VALVE,CHOKE 16126-3001
19 "0" RING 92055-510
20 WASHER 92022-537
21 SPRING 92081-528
22 SCREW,LOW SPEED 16009-3001
23 "0" RING,DRAIN PLUG 92055-1093
24 WASHER 92065-528
25 SPRING 92081-534
26 SCREW,HIGH SPEED 16009-3002
27 GASKET-BANJO BOLT 92065-078
28 BANJO-CARB 59071-505
29 BOLT,BANJO,#2.0 92001-3038
30 WASHER FLOAT VLV SEAT 16029-004
31 VALVE-SEAT 16030-503
32 SPRING 92081-536
33 FLOAT PIN 16032-006
34 ARM 59001-506
35 SCREW 3X7 92011-516
36 GASKET 11060-3706
37 DIAPHRAGM,CHECK SEAT 51069-501
38 PLATE-CARB. SIDE 59086-541
39 SCREW 3X7 92011-516
40 DIAPHRAGM,MAIN 51069-502
41 GASKET 11060-3704
42 BODY,DIAPHRAGM(1) 59021-514
43 GASKET 11009-3036
44 DIAPHRAGM,PUMP 43028-3002
45 BODY,DIAPHRAGM(2) 59336-3002
46 GASKET 11060-3705
47 DIAPHRAGM,PUMP 43028-3001
48 BODY,DIAPHRAGM(3) 59336-3003
49 SCREW 4X30 92011-515
50 GASKET 92065-526
51 COVER-CARB. SIDE 59036-530
52 SCREW 4X12 92011-510
