KAWASAKI
JS550
1986
Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1986 - Engine/Transmission - CARBURETOR
Engine/Transmission
CARBURETOR
No Part Part No Notes
1 CARBURETOR-ASSY 15001-2403-YR
2 NUT,THROTTLE LEVER 92015-3717
3 WASHER,THROTTLE LEVER 92022-3722
4 LEVER-ASSY-THROTTLE,THROTTLE 39074-3704
5 COLLAR,THROTTLE SHAFT 92027-2098
6 LEVER-THROTTLE,STOP 39075-2104
7 SPRING,THROTTLE SHAFT 92081-2336
8 BUSHING,CARBURETOR 92028-514
9 PACKING 43049-3702
10 SHAFT-CARBURETOR,THROTTLE 16041-2135
11 VALVE-THROTTLE 16025-2104
12 SCREW-PAN-CROS 220B0306
13 WASHER-SPRING,3MM 461F0300
14 SCREW,THROTTLE STOP 23013-2051
15 GASKET 92065-528
16 SPRING,THROTTLE CABLE BRACKET 16040-022
17 NEEDLE-JET,LOW SPEED 16009-3001
18 WASHER 92022-537
19 SPRING 92081-528
20 RING-O 92055-510
21 NEEDLE-JET,PILOT SCREW 16009-2092
22 RING-O 92055-511
23 SPRING 92081-534
24 NEEDLE-JET,HIGH SPEED 16009-3002
25 BOLT,4X8 92001-3026
26 TERMINAL,CHOKE SHAFT 21169-3008
27 SHAFT-CARBURETOR,CHOKE 16041-2136
28 WASHER,PLAIN,NYLON 92022-3020
29 RING-SNAP,5MM,SUS304 92033-3004
30 SPRING,CHOKE SHAFT 92081-2337
31 COLLAR,CHOKE SHAFT 92027-2097
32 PACKING,CHOKE SHAFT 11009-2465
33 WASHER,CHOKE SHAFT 92022-2221
34 PIN,SNAP 92043-2121
35 VALVE,CHOKE 16126-2114
36 SCREW,3X5 92009-2208
37 GASKET,FLOAT VALVE SEAT 16029-004
38 VALVE-FLOAT,2.0MM 16030-2066
39 SPRING 92081-536
40 PIN,FLOAT 16032-006
41 PLATE 59001-506
42 SCREW,3X7 92011-516
43 GASKET 92065-544
44 DIAPHRAGM,CHECK SHEET 51069-501
45 BRACKET,CARBURETOR 59086-541
46 DIAPHRAGM,MAIN,CARB 51069-502
47 GASKET 92065-531
48 CASE,PUMP 59021-514
49 GASKET 11009-3036
50 DIAPHRAGM,PUMP,CARBURETOR 43028-3002
51 CASE-PUMP 59336-3002
52 GASKET 92065-532
53 DIAPHRAGM,PUMP,CARBURETOR 43028-3001
54 CASE-PUMP 59336-3003
55 SCREW,4X30 92011-515
56 GASKET 92065-526
57 COVER,CARBURETOR 59036-530
58 SCREW,4X12 92011-510
