KAWASAKI
JS550
1983

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1983 - Engine/Transmission - CRANKSHAFT/PISTONS
Engine/Transmission
CRANKSHAFT/PISTONS
No Part Part No Notes
1 PISTON-ENGINE,STD 13001-3023
1 PISTON,0.50MM,Q.S. 13029-3004
2 RING-PISTON,STD 13003-3019
2 RING-PISTON,O/S 0.50 13003-3020
3 PIN-PISTON 13002-504
4 CIRCLIP PISTON PIN 92036-004
5 BEARING-SMALL END 13033-3005
6 CRANKSHAFT ASSY, 13031-3011
7 SHIM-1.0T 92025-532
8 SHIM 0.1T 92025-513
8 SHIM 0.2T 92025-518
8 SHIM 0.3T 92025-523
8 SHIM 0.4T 92025-527
8 SHIM 0.5T 92025-530
8 SHIM 0.6T 92025-533
9 BEARING-BALL 92045-505
10 O-RING 92055-504
11 PIN,DOWEL 551A0410
12 SLEEVE,CRANKSHAFT OUT 42036-3007
13 "0" RING,CRANKSHAFT 92055-3009
14 SEAL-OIL,TCY306210 92049-3005
15 SEAL-OIL,DCY30629 92049-3006
16 SEAL,OIL TCY306210 92050-507
17 WASHER 92022-3021
18 COUPLING 42034-3706
19 WASHER,18.5X38X4 92022-3028
20 WOODRUFF KEY 510A5200
21 WASHER,LOCK,20M/M 92022-569
22 NUT,20M/M 92015-535
