KAWASAKI - JS550 1986 - Engine/Transmission - CYLINDER HEAD/CYLINDER

Engine/Transmission
CYLINDER HEAD/CYLINDER
No	Part	Part No	Notes
1	CYLINDER-ENGINE	11005-2099-YR
2	STUD,8X42	92004-3016
3	STUD,8X50	92004-3017
4	NUT,CAP,8MM	92015-3003
5	WASHER-PLAIN,8MM	411S0800
6	GASKET-HEAD	11004-3024
7	HEAD-COMP-CYLINDER	11008-2059-YR
8	BRACKET,CARBURETOR	11044-2074
9	BOLT,6X16	110R0616
10	WASHER-PLAIN,6MM	411S0600
11	BRACKET,MUFFLER	11044-2075
12	BOLT,8X18	92002-2288
13	WASHER-PLAIN,8MM	411S0800
14	ELBOW	52014-3002
15	MANIFOLD-INTAKE	59076-2052-YR
16	GASKET,INTAKE	16062-510
17	STUD,8X27.5	92004-3022
18	BOLT-STUD,6X35	171R0635
19	BOLT,6X35	110R0635
20	BOLT,6X70	110R0670
21	NUT-HEX,6MM	311R0600
22	WASHER-PLAIN-SMALL,6MM	410S0600
23	MANIFOLD-EXHAUST	59081-2051-YR
24	GASKET,EXHAUST MANIFOLD	11009-3023
25	BOLT,6X25	110R0625
26	BOLT,6X70	110R0670
27	BOLT-STUD,6X25	171R0625
28	WASHER-PLAIN-SMALL,6MM	410S0600
29	NUT-HEX,6MM	311R0600
30	GASKET,CYLINDER	11009-3054
