KAWASAKI
XIR
1994

Spare Part Category
Show me all the part categories of the model
KAWASAKI - XIR 1994 - Frame - Cables
Frame
Cables
No Part Part No Notes
150 BOLT-WS,6X14 150R0614
410 W-PLAIN-S,10MM 410S1000
411 WASHER-PLAIN,8MM 411S0800
670 O RING,8MM 670B1508
670A O RING,11MM 670B2011
11046 BRACKET,STARTER CABLE 11046-3712
13091 HOLDER 13091-3712
13091A HOLDER,TUBE 13091-3758
13091B HOLDER 13091-3780
13183 PLATE 13183-3810
14044 HOLDER-CABLE 14044-3718
54012 CABLE-THROTTLE 54012-3741
54017 CABLE-STARTER 54017-3728
59101 REEL,STARTER CABLE 59101-3704
59406 CABLE-STRG 59406-3738
92009 SCREW,4X8 92009-3729
92009A SCREW,5X16 92009-3789
92015 NUT,20MM 92015-526
92022 WASHER,6.5X20X1.5 92022-3710
92022A WASHER 92022-535
92033 RING-SNAP,7MM 92033-3704
92036 RING-SNAP 92036-501
92071 GROMMET,HARNESS 92071-3790
92072 BAND,L=149 92072-031
92072A BAND 92072-3778
92077 KNOB 92077-3717
92140 BALL,3MM 92140-3702
92144 SPRING 92144-3712
92160 DAMPER 92160-1129
92170 CLAMP,CABLE 92170-3733
92180 SHIM,8.5X18X0.15 92180-3702
