KAWASAKI
300 SX
1987
Spare Part Category
Show me all the part categories of the model
KAWASAKI - 300 SX 1987 - Engine/Transmission - Carburetor(&NAMI.JS300AE022805)
Engine/Transmission
Carburetor(&NAMI.JS300AE022805)
No Part Part No Notes
223 SCREW-PAN-WS-CROS 223B0307
11009 GASKET 11009-3036
13236 LEVER-COMP,CHOKE 13236-3701
13320 LEVER-ASSY,THROTTLE 13320-3701
14024 COVER,CARBURETOR 14024-3721
15001 CARBURETOR-ASSY 15001-3716
16009 NEEDLE-JET,PILOT SCREW 16009-2092
16009A NEEDLE-JET,HIGH SPEED 16009-3002
16025 VALVE-THROTTLE,#140 16025-3702
16029 GASKET,FLOAT VALVE SEAT 16029-004
16030 VALVE-FLOAT,#1.8 16030-3702
16032 PIN,FLOAT 16032-006
16126 VALVE,CHOKE 16126-3701
39074 LEVER-ASSY-THROTTLE,SHAFT 39074-3703
39074A LEVER-ASSY-THROTTLE,THROTTLE 39074-3704
43028 DIAPHRAGM,PUMP,CARBURETOR 43028-3001
43028A DIAPHRAGM,PUMP,CARBURETOR 43028-3002
43028B DIAPHRAGM,PUMP 43028-3701
43049 PACKING 43049-3702
51069 DIAPHRAGM,CHECK SHEET 51069-501
51069A DIAPHRAGM,MAIN,CARB 51069-502
59001 PLATE 59001-506
59086 BRACKET,CARBURETOR 59086-541
59336 CASE-PUMP 59336-3002
59336A CASE-PUMP 59336-3003
92009 SCREW,CHOKE VALVE 92009-3704
92009A SCREW,CHOKE LEVER 92009-3705
92009B SCREW 92009-3714
92011 SCREW,4X12 92011-510
92011A SCREW,4X30 92011-515
92015 NUT,THROTTLE LEVER 92015-3717
92022 WASHER,THROTTLE LEVER 92022-3722
92022A WASHER 92022-537
92027 COLLAR,THROTTLE SHAFT 92027-3709
92028 BUSHING,CARBURETOR 92028-3730
92055 RING-O 92055-510
92055A RING-O 92055-511
92065 GASKET 92065-526
92065A GASKET 92065-528
92065B GASKET 92065-531
92065C GASKET 92065-532
92065D GASKET 92065-544
92081 SPRING,CHOKE SHAFT 92081-3705
92081A SPRING 92081-528
92081B SPRING 92081-534
92144 SPRING 92144-3709
92144A SPRING,THROTTLE SHAFT 92144-3715
