KAWASAKI
300 SX
1991

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 300 SX 1991 - Engine/Transmission - Carburetor(JS300-A3/A4/A5)
Engine/Transmission
Carburetor(JS300-A3/A4/A5)
No Part Part No Notes
11009 GASKET 11009-3036
11012 CAP,JET NEEDLE 11012-3739
11060 GASKET 11060-3704
11060A GASKET 11060-3705
11060B GASKET 11060-3706
13168 LEVER,THROTTLE SHAFT 13168-3706
14024 COVER,CARBURETOR 14024-3721
14037 SCREEN,CARBURETOR 14037-504
15001 CARBURETOR-ASSY 15001-3755
16009 NEEDLE-JET 16009-3708
16009A NEEDLE-JET,HIGH SPEED 16009-3709
16021 SCREW-THROTTLE STOP 16021-3703
16029 GASKET,FLOAT VALVE SEAT 16029-004
16030 VALVE-FLOAT,#1.8 16030-3702
16032 PIN,FLOAT 16032-006
16040 SPRING,THROTTLE CABLE BRACKET 16040-022
39074 LEVER-ASSY-THROTTLE,THROTTLE 39074-3704
43028 DIAPHRAGM,PUMP,CARBURETOR 43028-3001
43028A DIAPHRAGM,PUMP,CARBURETOR 43028-3002
43028B DIAPHRAGM,PUMP 43028-3701
43028C DIAPHRAGM,CHECK SHEET 43028-3705
51069 DIAPHRAGM,MAIN,CARB 51069-502
59001 PLATE 59001-506
59086 BRACKET,CARBURETOR 59086-541
59336 CASE-PUMP 59336-3002
59336A CASE-PUMP 59336-3003
92009 SCREW,CHOKE LEVER 92009-3705
92009A SCREW 92009-3714
92011 SCREW,4X12 92011-510
92015 NUT,THROTTLE LEVER 92015-3717
92022 WASHER,THROTTLE LEVER 92022-3722
92022A WASHER 92022-3758
92022B WASHER 92022-537
92027 COLLAR,THROTTLE SHAFT 92027-3709
92028 BUSHING,CARBURETOR 92028-3730
92055 RING-O 92055-510
92055A RING-O 92055-511
92065 GASKET 92065-526
92065A GASKET 92065-528
92081 SPRING 92081-528
92081A SPRING 92081-534
92144 SPRING 92144-3709
92144A SPRING,THROTTLE SHAFT 92144-3715
92150 BOLT 92150-3757
