Engine/Transmission
|
|
Carburetor
|
|
| No |
Part |
Part No |
Notes |
|
11009
|
PACKING,CHOKE SHAFT |
11009-2465 |
|
|
11009A
|
GASKET |
11009-3036 |
|
|
11009B
|
GASKET,FLOAT VALVE SEAT |
16029-004 |
|
|
11009C
|
GASKET |
92065-526 |
|
|
11009D
|
GASKET |
92065-528 |
|
|
11009E
|
GASKET |
92065-531 |
|
|
11009F
|
GASKET |
92065-532 |
|
|
11009G
|
GASKET |
92065-544 |
|
|
11012
|
CAP,JET NEEDLE |
11012-3739 |
|
|
11034
|
BRACKET,CARBURETOR |
59086-541 |
|
|
13169
|
PLATE |
59001-506 |
|
|
14024
|
COVER,CARBURETOR |
59036-530 |
|
|
14037
|
SCREEN,CARBURETOR |
14037-504 |
|
|
15001
|
CARBURETOR-ASSY |
15001-3753 |
|
|
16009
|
NEEDLE-JET |
16009-3708 |
|
|
16009A
|
NEEDLE-JET,HIGH SPEED |
16009-3709 |
|
|
16009B
|
NEEDLE-JET |
16009-3710 |
|
|
16030
|
VALVE-FLOAT,2.0MM |
16030-2066 |
|
|
21169
|
TERMINAL,CHOKE SHAFT |
21169-3008 |
|
|
23013
|
SCREW,THROTTLE STOP |
23013-2051 |
|
|
32099
|
CASE,PUMP |
59021-514 |
|
|
39074
|
LEVER-ASSY-THROTTLE,THROTTLE |
39074-3704 |
|
|
39075
|
LEVER-THROTTLE,STOP |
39075-2104 |
|
|
43028
|
DIAPHRAGM,PUMP,CARBURETOR |
43028-3001 |
|
|
43028A
|
DIAPHRAGM,PUMP,CARBURETOR |
43028-3002 |
|
|
43028B
|
DIAPHRAGM,CHECK SHEET |
51069-501 |
|
|
43028C
|
DIAPHRAGM,MAIN,CARB |
51069-502 |
|
|
59336
|
CASE-PUMP |
59336-3002 |
|
|
59336A
|
CASE-PUMP |
59336-3003 |
|
|
92001
|
BOLT,4X8 |
92001-3026 |
|
|
92009
|
SCREW |
92009-3714 |
|
|
92009A
|
SCREW,4X12 |
92011-510 |
|
|
92015
|
NUT,THROTTLE LEVER |
92015-3717 |
|
|
92022
|
WASHER,CHOKE SHAFT |
92022-2221 |
|
|
92022A
|
WASHER,PLAIN,NYLON |
92022-3020 |
|
|
92022B
|
WASHER,THROTTLE LEVER |
92022-3722 |
|
|
92022C
|
WASHER |
92022-537 |
|
|
92028
|
BUSHING,CARBURETOR |
92028-514 |
|
|
92033
|
RING-SNAP,5MM,SUS304 |
92033-3004 |
|
|
92043
|
PIN,FLOAT |
16032-006 |
|
|
92043A
|
PIN,SNAP |
92043-2121 |
|
|
92055
|
RING-O |
92055-510 |
|
|
92055A
|
RING-O |
92055-511 |
|
|
92081
|
SPRING,THROTTLE CABLE BRACKET |
16040-022 |
|
|
92081A
|
SPRING,THROTTLE SHAFT |
92081-2336 |
|
|
92081B
|
SPRING |
92081-528 |
|
|
92081C
|
SPRING |
92081-534 |
|
|
92081D
|
SPRING |
92081-536 |
|
|
92143
|
COLLAR,THROTTLE SHAFT |
92027-2098 |
|
|
92150
|
BOLT |
92150-3757 |
|
|
92200
|
WASHER |
92022-3758 |
|
|
|
|
