KAWASAKI
650 SX
1992

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 650 SX 1992 - Engine/Transmission - Carburetor
Engine/Transmission
Carburetor
No Part Part No Notes
220 SCREW-PAN-CROS 220D0408
11009 GASKET,DIAPHRAGM 11009-3730
14090 COVER,DIAPHRAGM 14090-3702
15001 CARBURETOR-ASSY 15001-3758
16009 NEEDLE-JET,MAIN 16009-3711
16009A NEEDLE-JET,SLOW 16009-3712
16021 SCREW-THROTTLE STOP 16021-3702
16030 VALVE-FLOAT 16030-3701
16055 ARM-FLOAT 16055-3701
16087 VALVE-CHECK 16087-3703
16158 JET-SLOW 16158-3705
32099 CASE,CARBURETOR 32099-3754
43028 DIAPHRAGM,CARBURETOR 43028-3704
43028A DIAPHRAGM,PUMP 43028-3706
49019 FILTER-FUEL,STRAINER 49019-3707
59336 CASE-PUMP 59336-3709
92009 SCREW,3X6 92009-3712
92009A SCREW,4X18 92009-3782
92009B SCREW,5X28 92009-3783
92037 CLAMP 92037-1173
92043 PIN,FLOAT 92043-1209
92043A PIN,THROTTLE STOP SCREW 92043-3712
92055 RING-O 92055-1246
92055A RING-O,ADJUST SCREW 92055-3713
92055B RING-O 92055-3734
92063 JET-MAIN,#140 92063-3701
92143 COLLAR,THROTTLE STOP SCREW 92143-3709
92143A COLLAR 92143-3727
92144 SPRING,THROTTLE STOP SCREW 92144-3706
92144A SPRING,FLOAT ARM 92144-3733
92190 TUBE,PULSE 92190-3730
