KAWASAKI
JS440
1987
Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS440 1987 - Engine/Transmission - Carburetor
Engine/Transmission
Carburetor
No Part Part No Notes
1 CARBURETOR-ASSY 15001-3719
2 SPRING,THROTTLE SHAFT 92144-3715
3 BUSHING,CARBURETOR 92028-3730
4 PACKING 43049-3702
5 LEVER-ASSY-THROTTLE,SHAFT 39074-3713
6 SPRING,THROTTLE CABLE BRACKET 16040-022
7 SCREW,4X20 92009-3009
8 BOLT,4X8 92001-3026
9 SPRING 92081-525
10 SHAFT-CARBURETOR,CHOKE 16041-2168
11 RING-SNAP,5MM,SUS304 92033-3004
12 WASHER,PLAIN,NYLON 92022-3020
13 TERMINAL,CHOKE SHAFT 21169-3008
14 SCREW-PAN-WS-CROS 223B0307
15 LEVER,THROTTLE SHAFT 13168-3703
16 VALVE-THROTTLE 16025-503
17 SCREW-PAN-WS-CROS,3X6 223B0306
18 VALVE,CHOKE 16126-3001
19 RING-O 92055-510
20 WASHER 92022-537
21 SPRING 92081-528
22 NEEDLE-JET,LOW SPEED 16009-3001
23 RING-O 92055-511
24 GASKET 92065-528
25 SPRING 92081-534
26 NEEDLE-JET,HIGH SPEED 16009-3002
27 GASKET,BANJO BOLT 92065-078
28 JOINT,BANJO 59071-505
29 BOLT,BANJO 92003-521
30 GASKET,FLOAT VALVE SEAT 16029-004
31 VALVE-FLOAT,#1.5 16030-503
32 SPRING 92081-536
33 PIN,FLOAT 16032-006
34 PLATE 59001-506
35 SCREW 92009-3714
36 GASKET 92065-544
37 DIAPHRAGM,CHECK SHEET 51069-501
38 BRACKET,CARBURETOR 59086-541
39 SCREW 92009-3714
40 DIAPHRAGM,MAIN,CARB 51069-502
41 GASKET 92065-531
42 CASE,PUMP 59021-514
43 GASKET 11009-3036
44 DIAPHRAGM,PUMP,CARBURETOR 43028-3002
45 CASE-PUMP 59336-3002
46 GASKET 92065-532
47 DIAPHRAGM,PUMP,CARBURETOR 43028-3001
48 CASE-PUMP 59336-3003
49 SCREW,4X30 92011-515
50 GASKET 92065-526
51 COVER,CARBURETOR 59036-530
52 SCREW,4X12 92011-510
53 COLLAR,THROTTLE SHAFT 92027-3709
54 LEVER-ASSY-THROTTLE,THROTTLE 39074-3704
55 WASHER,THROTTLE LEVER 92022-3722
56 NUT,THROTTLE LEVER 92015-3717
