KAWASAKI
ULTRA LX
2014

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA LX 2014 - Engine/Transmission - Cooling
Engine/Transmission
Cooling
No Part Part No Notes
130 BOLT-FLANGED,8X50 130BD0850
132 BOLT-FLANGED-SMALL,6X20 132BD0620
670 O RING,14MM 670D2014
13091 HOLDER 13091-3712
14091 COVER,INSIDE 14091-3755
14091A COVER,OUTSIDE 14091-3756
27010 SWITCH,OIL PRESSURE 27010-3786
39067 COOLER-OIL 39067-3704
59071 JOINT 59071-3764
92005 FITTING,WATER TEMP SENSOR 92005-0733
92005A FITTING 92005-3714
92005B FITTING,FLUSH 92005-3748
92005C FITTING,FLUSH 92005-3757
92055 RING-O,58X3 92055-3767
92055A RING-O 92055-3770
92055B RING-O 92055-3772
92066 PLUG 92066-3787
92071 GROMMET 92071-3815
92072 BAND,L=188.85 92072-0105
92072A BAND,L=152 92072-3874
92072B BAND 92072-3877
92072C BAND,L=100.08 92072-3882
92153 BOLT,OIL COOLER 92153-3713
92161 DAMPER 92161-1331
92171 CLAMP 92171-3701
92171A CLAMP 92171-3714
92173 CLAMP 92173-1482
92191 TUBE,CHAMBER-TAIL PIPE 92191-3850
92191A TUBE,CORRUGATED,19.5X23.8X500 92191-3884
92192 TUBE,12X18X250 92192-1046
92192A TUBE,12X18X1250 92192-1047
92192B TUBE,CORRUGATED,19.5X23.8X200 92192-1048
92192C TUBE,CORRUGATED,19.5X23.8X1200 92192-1049
92192E TUBE,CORRUGATED,19.5X23.8X900 92192-3711
92192F TUBE,CORRUGATED,19.5X23.8X380 92192-3714
92192G TUBE,12X18X630 92192-3716
92192H TUBE,GENERATOR-HULL 92192-3739
92192I TUBE,12X18X1000 92192-3740
92192J TUBE,12X18X480 92192-3742
92192K TUBE,12X18X450 92192-3745
92192L TUBE,WATER MUFFLER-HULL 92192-3746
92192M TUBE,CORRUGATED,L=600M 92192-3751
92192N TUBE,CORRUGATED,19.5X23.8X800 92192-3781
92192O TUBE,12X19X120 92192-3796
92192P TUBE,12X19X55&1000 92192-3799
92192Q TUBE,7X12X1590 92192-3848
