KAWASAKI
550 SX
1995

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 550 SX 1995 - Engine/Transmission - Crankshaft/Piston(s)
Engine/Transmission
Crankshaft/Piston(s)
No Part Part No Notes
551 PIN-DOWEL 551A0410
13001 PISTON-ENGINE,STD 13001-3704
13002 PIN-PISTON 13002-504
13008 RING-SET-PISTON,STD 13008-3703
13024 RING-SET-PISTON LL,O/S 1.00 13024-3703
13025 RING-SET-PISTON L,O/S 0.50 13025-3703
13027 PISTON-ENGINE LL,O/S 1.00 13027-3704
13029 PISTON-ENGINE L,O/S 0.50 13029-3704
13031 CRANKSHAFT-COMP 13031-3715
13033 BEARING-NEEDLE,KBK16X20X22.8X6 13033-3005
42036 SLEEVE,CRANKSHAFT OUT 42036-3007
92022 WASHER,CRANK,RH 92022-3021
92025 SHIM,T=0.1 92025-513
92025A SHIM,T=0.2 92025-518
92025B SHIM,T=0.3 92025-523
92025C SHIM,T=0.4 92025-527
92025D SHIM,T=0.5 92025-530
92025E SHIM,T=1.0MM 92025-532
92025F SHIM,T=0.6 92025-533
92036 RING-SNAP 92036-507
92045 BEARING-BALL 92045-3010
92049 SEAL-OIL,OIL,TCY306210 92049-3005
92049A SEAL-OIL,OIL,DCY30629 92049-3006
92055 RING-O,22MM 92055-3009
92055A RING-O 92055-504
