KAWASAKI
JS550
1984

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1984 - Engine/Transmission - DRIVE SHAFT
Engine/Transmission
DRIVE SHAFT
No Part Part No Notes
1 HOLDER 41046-502
2 SEAL,OIL AC1799EX 92050-501
3 SHAFT,DRIVE 13107-3008
4 BEARING BALL #6305 601B6305
5 COLLAR 92027-502
6 SLEEVE,BEARING 42036-501
7 SLEEVE,BEARING 42036-501
8 "0" RING 92055-501
9 SEAL,OIL AC1799EX 92050-501
10 BOLT,8X25 110R0825
11 WASHER SPRING 8MM 461S0800
12 WASHER 411S0800
13 SHIM 0.15T 92025-502
13 SHIM 0.3T 92025-503
14 NIPPLE,GREASE 92005-501
15 PIN,DOWEL 551R0612
16 COUPLING 42034-3706
17 BOLT,8X25 110R0825
18 WASHER SPRING 8MM 461S0800
19 WASHER 411S0800
20 DAMPER RUBBER,COUPLNG 92075-520
21 COVER,COUPLING 59036-567
22 BOLT 6X16 110R0616
23 WASHER-SPRING,6MM 461S0600
24 WASHER 411S0600
25 SHIM,T=0.3 92025-3701
25 SHIM.T=0.5 92025-3702
25 SHIM,T=1.0 92025-3703
25 SHIM,T=1.5MM 92025-3704
