Electrical
|
|
ELECTRIC CASE
|
|
| No |
Part |
Part No |
Notes |
|
1
|
SPARK PLUG B7ES |
B7ES |
|
|
2
|
CAP,PLUG |
21130-504 |
|
|
3
|
.SPRING,PLUG CAP |
92081-542 |
|
|
4
|
COVER,PLUG |
92071-501 |
|
|
5
|
GROMMET |
92071-517 |
|
|
6
|
BOLT,6X30 |
92001-3022 |
|
|
7
|
WASHER |
411S0600 |
|
|
8
|
WASHER |
92022-553 |
|
|
9
|
COLLAR |
92027-519 |
|
|
10
|
CLAMP |
92037-523 |
|
|
11
|
BRACKET,CLAMP |
59016-514 |
|
|
12
|
NUT,6M/M |
311R0600 |
|
|
13
|
BOLT 6X14 |
110R0614 |
|
|
14
|
WASHER-SPRING,6MM |
461S0600 |
|
|
15
|
PLATE-ELECTRICAL CASE |
59086-516 |
|
|
16
|
GROMMET |
92071-526 |
|
|
17
|
BOX,ELECTRIC(1) |
59021-518-9G |
|
|
18
|
BOX,ELECTRIC (2) |
59021-526-9G |
|
|
19
|
GASKET,CASE |
11009-3024 |
|
|
20
|
BOLT 6X22 |
110R0622 |
|
|
21
|
WASHER-SPRING,6MM |
461S0600 |
|
|
22
|
WASHER |
410S0600 |
|
|
23
|
REGULATOR |
21066-501 |
|
|
24
|
BOLT-UPSET 6X14 |
112B0614 |
|
|
25
|
WASHER PLAIN 6MM |
410B0600 |
|
|
26
|
WASHER SPRING 6MM |
461F0600 |
|
|
27
|
SWITCH,MAGNETIC |
21164-515 |
|
|
28
|
BOLT SMALL |
114G0812 |
|
|
29
|
WASHER SPRING 5MM |
461F0500 |
|
|
30
|
IGNITER |
21119-3004 |
|
|
31
|
BOLT-UPSET-WS,6X22 |
180B0622 |
|
|
32
|
WASHER,IGNITER |
92022-3013 |
|
|
33
|
COIL,IGNITION |
21121-518 |
|
|
34
|
NUT 6MM |
311B0600 |
|
|
35
|
WASHER SPRING 6MM |
461F0600 |
|
|
36
|
BRACKET,COIL |
59016-521 |
|
|
37
|
BOLT-UPSET-WS,6X14 |
180B0614 |
|
|
38
|
GROMMET |
92071-527 |
|
|
39
|
WIRE,SWITCH |
26011-504 |
|
|
40
|
WIRE,EARTH |
26011-505 |
|
|
41
|
WIRE,STARTER |
26011-510 |
|
|
42
|
WIRE,BATTERY |
26011-511 |
|
|
43
|
DASHBOARD |
59226-503-9H |
|
|
44
|
SCREW,6X20 |
220R0620 |
|
|
45
|
WASHER-SPRING,6MM |
461S0600 |
|
|
46
|
WASHER |
411S0600 |
|
|
47
|
CABLE,CHOKE |
59401-3001 |
|
|
48
|
GASKET |
92065-538 |
|
|
49
|
CLAMP |
92037-532 |
|
|
50
|
NUT 6M/M |
312R0600 |
|
|
51
|
WASHER-SPRING,6MM |
461S0600 |
|
|
52
|
WASHER |
411S0600 |
|
|
53
|
BOLT 6X12 |
110R0612 |
|
|
54
|
BOX,SWITCH |
59191-502 |
|
|
55
|
.STUD |
171R0514A |
|
|
56
|
GASKET,UNIT BOX |
92065-511 |
|
|
57
|
BOLT 6X99 |
110R0699 |
|
|
58
|
WASHER-SPRING,6MM |
461S0600 |
|
|
59
|
WASHER |
411S0600 |
|
|
60
|
SWITCH,STARTER |
21164-511 |
|
|
61
|
SWITCH,STOP |
21164-512 |
|
|
62
|
RETAINER,SWITCH |
23072-515 |
|
|
63
|
NUT,5MM |
311B0500 |
|
|
64
|
WASHER SPRING 5MM |
461F0500 |
|
|
65
|
WASHER PLAIN 5MM |
411B0500 |
|
|
66
|
WIRE,BATTERY EARTH |
26011-501 |
|
|
67
|
FB BAT 12N16-3B |
26012-1013 |
|
|
68
|
CAP-BATTERY TERMINAL |
59176-501 |
|
|
69
|
PLATE-BATTERY |
59086-520 |
|
|
70
|
CUSHION,BATTERY |
92075-509 |
|
|
71
|
BAND,BATTERY |
92072-512 |
|
|
72
|
JOINT-STATOR WIRE |
59071-516 |
|
|
73
|
"0" RING,16MM |
670B2016 |
|
|
74
|
BAND,MIDDLE |
92072-031 |
|
|
|
|
