KAWASAKI
JS440
1979
Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS440 1979 - Electrical - ELECTRIC CASE (JS440-A3/A4/A4A)
Electrical
ELECTRIC CASE (JS440-A3/A4/A4A)
No Part Part No Notes
1 CASE,ELECTRIC 59416-3001
2 CASE,ELECTRIC (2) 59021-532
3 GASKET,CASE 11009-3024
4 CLAMP,L=100 92037-3736
5 TUBE,VINYL,5X73 92059-3017
6 WIRE,EARTH 26011-505
7 BOLT,HEX HEAD,6X25 110R0625
8 WASHER 411S0600
9 WASHER-SPRING,6MM 461S0600
10 CONNECTOR,CORD 59221-505
11 WIRE,LEAD 26011-512
12 WIRE,LEAD 26011-513
13 WIRE,LEAD 26011-514
14 WIRE,LEAD 26011-515
15 JOINT-STATOR WIRE 59071-516
16 "0" RING,16MM 670B2016
17 GROMMET 92071-526
18 PLATE-ELECTRICAL CASE 59086-516
19 BOLT 6X14 110R0614
20 WASHER-SPRING,6MM 461S0600
21 REGULATOR 21066-501
22 BOLT-UPSET 6X14 112B0614
23 WASHER SPRING 6MM 461F0600
24 WASHER PLAIN 6MM 411B0600
25 SWITCH,MAGNETIC 21164-515
26 WIRE,LEAD 26011-516
27 WIRE,LEAD,BATTERY 26011-3002
28 WIRE,LEAD,STARTER 26011-519
29 CAP 11012-3012
30 CAP,STARTER 59176-506
31 GROMMET 92071-527
32 BOLT SMALL 114G0812
33 WASHER SPRING 5MM 461F0500
34 WASHER PLAIN 5MM 411B0500
35 IGNITER 21119-3004
36 WASHER,IGNITER 92022-3013
37 BOLT 6X22 112B0622
38 WASHER SPRING 6MM 461F0600
40 COIL,IGNITION 21121-518
41 CAP SPARK PLUG 21130-009
42 SPRING-SPARK PLUG CAP 92101-001
43 GROMMET 92071-517
44 BRACKET,COIL 59016-521
45 COVER,PLUG 92071-501
46 RELAY, 27034-3001
47 BOLT-UPSET 6X14 112B0614
48 WASHER SPRING 6MM 461F0600
49 NUT 6MM 311B0600
50 BOLT-UPSET,6X20 112G0620
51 WASHER PLAIN 6MM 411B0600
52 HARNESS,SWITCH 26001-3005
53 BRACKET,CLAMP 11034-3005
54 CLAMP 92037-523
55 WASHER 92022-553
56 WASHER 92022-553
57 COLLAR 92027-519
58 BOLT,6X30 92001-3022
59 STUD,6X20 171R0620
60 NUT,6M/M 311R0600
61 WASHER 411S0600
62 CASE,FUEL TAP 32099-3752
63 STUD,6X98 92004-3007
64 NUT,6M/M 311R0600
65 WASHER 411S0600
66 WASHER-SPRING,6MM 461S0600
67 PANEL-CONTROL 59226-3702
68 SCREW,CNTSNK HEAD8X22 92009-3004
69 WIRE-LEAD,BATTERY(-) 26011-3776
70 FB BAT 12N16-3B 26012-1013
71 CAP-BATTERY TERMINAL 59176-501
72 PLATE-BATTERY 59086-520
73 CUSHION,BATTERY 92075-509
74 BAND,BATTERY 92072-512
75 BOLT 6X14 110R0614
76 WASHER-SPRING,6MM 461S0600
77 CASE,CONNECTOR 32099-3002
78 NUT,6M/M 311R0600
79 WASHER 411S0600
80 WASHER-SPRING,6MM 461S0600
81 SPARK PLUG B7ES 92070-3003
