Body Parts
|
Fuel Tank
|
|
No |
Part |
Part No |
Notes |
110
|
BOLT,6X16 |
110R0616 |
|
150
|
BOLT-WS,6X12 |
150R0612 |
|
11009
|
GASKET,TANK CAP |
11009-3020 |
|
11044
|
BRACKET,FUEL PIPE |
11044-3718 |
|
11045
|
BRACKET |
11045-3757 |
|
11045A
|
BRACKET |
11045-3760 |
|
13091
|
HOLDER,FUEL PIPE |
13091-3709 |
|
16115
|
CAP-OIL FILLER |
16115-3705 |
|
23072
|
RETAINER |
23072-501 |
|
31064
|
PIPE-COMP,FUEL |
31064-3717 |
|
49019
|
FILTER-FUEL |
49019-3706 |
|
49057
|
VALVE-RELIEF |
49057-3001 |
|
49105
|
BRACKET-TAP |
49105-3704 |
|
51004
|
TANK-FUEL |
51004-3704 |
|
51023
|
TAP-ASSY,FUEL |
51023-3716 |
|
51036
|
CUP,FUEL FILTER |
51036-3702 |
|
51049
|
CAP-TANK,FUEL |
51049-3705 |
|
52001
|
TANK-OIL |
52001-3704 |
|
59231
|
FILLER,FUEL TANK |
59231-3702 |
|
59231A
|
FILLER,OIL TANK |
59231-3703 |
|
92009
|
SCREW,4X8 |
92009-3729 |
|
92011
|
SCREW |
92011-562 |
|
92015
|
NUT,RING |
92015-3013 |
|
92022
|
WASHER |
92022-563 |
|
92037
|
CLAMP |
92037-1173 |
|
92037A
|
CLAMP |
92037-3009 |
|
92037B
|
CLAMP |
92037-3726 |
|
92037C
|
CLAMP,L=100 |
92037-3736 |
|
92055
|
RING-O,FILTER CUP |
92055-3006 |
|
92057
|
CHAIN,COVER,L=100 |
92057-3704 |
|
92065
|
GASKET |
92065-504 |
|
92071
|
GROMMET |
92071-3745 |
|
92072
|
BAND,L=186 |
92072-056 |
|
92075
|
DAMPER |
92075-3728 |
|
92077
|
KNOB,FUEL TAP |
92077-3704 |
|
92150
|
BOLT,6X12 |
92150-3709 |
|
92150A
|
BOLT,5X16 |
92150-3778 |
|
92190
|
TUBE,5.8X10.8X55 |
92190-3765 |
|
92190A
|
TUBE,5.8X10.8X370 |
92190-3864 |
|
92190B
|
TUBE,5.8X10.8X1380 |
92190-3865 |
|
92190C
|
TUBE |
92190-3866 |
|
92190D
|
TUBE,"RES",5.8X10.8X1400 |
92190-3867 |
|
92190E
|
TUBE,"ON",5.8X10.8X1400 |
92190-3868 |
|
92190F
|
TUBE,"RETURN",7X12X910 |
92190-3869 |
|
92190G
|
TUBE,5.8X10.8X490 |
92190-3870 |
|
92190H
|
TUBE,45X53X75 |
92190-3871 |
|
92190I
|
TUBE |
92190-3873 |
|
92190J
|
TUBE |
92190-3874 |
|
|
|
|
