KAWASAKI
JS300
1986

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS300 1986 - Body Parts - HANDLEBAR
Body Parts
HANDLEBAR
No Part Part No Notes
110 BOLT,5X10 110R0510
156 BOLT-WP,5X25 156R0525
220 SCREW-PAN-CROS,5X20 220R0520
221 SCREW,6X25 221R0625
410 WASHER,PLAIN,5MM 410S0500
461 WASHER-SPRING,5MM 461S0500
461A WASHER-SPRING,6MM 461S0600
670 "O" RING,8MM 670B1508
13091 HOLDER 13091-3726
13169 PLATE,HANDLEBAR 13169-3004
14024 COVER,THROTTLE LEVER 14024-3701
21083 ARM,THROTTLE LEVER 21083-3701
27004 SWITCH-ASSY 27004-3704
27010 SWITCH,STOP&START 27010-3707
32085 STOPPER 32085-3705
32085A STOPPER 32085-3709
32099 CASE,FR 32099-3724
32099A CASE,LWR 32099-3725
32099B CASE,UPP 32099-3726
39063 HOUSING-CONTROL,UPP 39063-3703
39063A HOUSING-CONTROL,LWR 39063-3705
39074 LEVER-ASSY-THROTTLE 39074-3711
39075 LEVER-THROTTLE 39075-3704
43049 PACKING,THROTTLE LEVE 43049-3701
46003 HANDLE 46003-3703
46075 GRIP,HANDLEBAR 46075-3713
59266 JOINT-BALL 59266-3707
92002 BOLT,SOCKET,3X10 92002-3751
92009 SCREW,8X22 92009-3701
92009A SCREW 92009-3703
92027 COLLAR,THROTTLE LEVER 92027-3704
92037 CLAMP,HANDLE PIPE 92037-503
92072 BAND,MIDDLE 92072-031
92081 SPRING,THROTTLE LEVER 92081-3702
