Body Parts
|
HANDLEBAR (JS550-A6)
|
|
No |
Part |
Part No |
Notes |
1
|
PLATE,HANDLEBAR |
13169-3004 |
|
2
|
SCREW,8X22 |
92009-3701 |
|
3
|
WASHER-SPRING,6MM |
461S0600 |
|
4
|
JOINT-BALL |
59266-3701 |
|
5
|
HANDLE |
46003-3703 |
|
6
|
CLAMP,HANDLEBAR |
92037-503 |
|
7
|
GRIP,HANDLEBAR |
46075-3709 |
|
8
|
STOPPER |
32085-3705 |
|
9
|
SCREW,6X16 |
92009-3703 |
|
10
|
BAND,L=149 |
92072-031 |
|
11
|
SWITCH-ASSY |
27004-3002 |
|
12
|
SCREW-PAN-CROS,5X20 |
220R0520 |
|
13
|
W-PLAIN-S,5MM |
410S0500 |
|
14
|
TUBE,SPIRAL |
92059-3010 |
|
15
|
LEVER-ASSY-THROTTLE |
39074-3706 |
|
16
|
HOUSING-CONTROL,UPP |
39063-3703 |
|
17
|
BOLT,SOCKET,3X10 |
92002-3751 |
|
18
|
LEVER-THROTTLE |
39075-3703 |
|
19
|
COVER,THROTTLE LEVER |
14024-3701 |
|
20
|
BOLT,5X10 |
110R0510 |
|
21
|
WASHER-SPRING,5MM |
461S0500 |
|
22
|
W-PLAIN-S,5MM |
410S0500 |
|
23
|
ARM,THROTTLE LEVER |
21083-3701 |
|
24
|
SPRING,THROTTLE LEVER RETURN |
92081-3702 |
|
25
|
COLLAR,THROTTLE LEVER |
92027-3704 |
|
26
|
HOUSING-CONTROL,LWR |
39063-3704 |
|
27
|
BOLT,5X25 |
110R0525 |
|
28
|
STOPPER |
32085-3706 |
|
29
|
O RING,8MM |
670B1508 |
|
30
|
PACKING,THROTTLE LEVER |
43049-3701 |
|
31
|
HOLDER,SWITCH |
13091-3726 |
|
32
|
SCREW-CSK-CROS,6X25 |
221R0625 |
|
33
|
SWITCH,STOP&START |
27010-3708 |
|
34
|
CASE,FR,SWITCH |
32099-3724 |
|
35
|
CASE,LWR,SWITCH |
32099-3725 |
|
36
|
CASE,UPP,SWITCH |
32099-3726 |
|
|
|
|
