KAWASAKI
JS550
1984

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1984 - Frame - HULL/ENGINE HOOD (JS550-A1/A2)
Frame
HULL/ENGINE HOOD (JS550-A1/A2)
No Part Part No Notes
1 HULL-ASSY,JET-WHITE 59431-3704-8C
2 HULL EXTENSION-LH 59251-3006-8C
3 HULL EXTENSION-RH 59251-3005-8C
4 CASE-ASSY-FIRE 32099-5501
5 RIVET 59281-506
6 CAP,FIRE EXT.BLACK 11012-3724
7 "0" RING 671B2585
8 HOOK 27012-501
9 HOOK 27012-502
10 SCREW 0.22 X 0.563 92011-561
11 BUSHING 92028-3013
12 DAMPER,6.0TX90X300 92075-521
13 DAMPER,3.OTX90X200 92075-522
14 GASKET,ENGINE COVER 92065-539
15 MAT 59131-502
16 BUMPER 59201-502
17 DETENT,STEERING CABLE 59346-504
18 STABILIZER 59437-3002
19 WASHER,5X16X1.5 92022-3041
20 RIVET 92039-3002
21 INST JS STABILIZER 99969-0560
22 HOOD-COMP-ENGINE,JET 59456-3719-8C
23 BAND,HOOD 92072-3746
24 BOLT,6X30 92001-3022
25 WASHER,BAND 92022-509
26 PLATE-ENG. CVR. STRAP 59086-501
27 NUT,6M/M 311R0600
28 LEVER 13168-3701
29 DETENT-HOOD LEVER 59346-503
30 SCREW 0.16X0.5 92011-562
31 HINGE-HOOD LEVER 53009-503
