Body Parts
|
Handle Pole
|
|
No |
Part |
Part No |
Notes |
154
|
BOLT-WP-SMALL,8X35 |
154R0835 |
|
156
|
BOLT-WP,5X20 |
156R0520 |
|
156A
|
BOLT-WP |
156R0635 |
|
225
|
SCREW-PAN-WSP-CROS,6X16 |
225R0616 |
|
314
|
NUT-HEX-FINE,10MM |
314R1000 |
|
410
|
W-PLAIN-S,10MM |
410S1000 |
|
461
|
WASHER-SPRING,6MM |
461S0600 |
|
461A
|
WASHER-SPRING,10MM |
461S1000 |
|
551
|
PIN-DOWEL |
551R0408 |
|
551A
|
PIN-DOWEL,6X25 |
551R0625 |
|
11012
|
CAP,BRACKET,LWR |
11012-3751 |
|
11012A
|
CAP,LEVER GRIP |
11012-3755 |
|
11047
|
BRACKET,CABLE JOINT |
11047-3723 |
|
11047A
|
BRACKET,STEERING SHAFT,UPP |
11047-3726 |
|
11047B
|
BRACKET,STEERING SHAFT |
11047-3728 |

11047B - BRACKET,STEERING SHAFT
*|*( - KAW91300 91 )
|
11047C
|
BRACKET,STEERING,LWR |
11047-3729 |
|
11047E
|
BRACKET,STEERING SHAFT |
11047-3771 |

11047E - BRACKET,STEERING SHAFT
*|*(KAW91301 91 - )
|
13070
|
GUIDE,SLIDE |
13070-3703 |
|
13070A
|
GUIDE,SLIDE |
13070-3704 |
|
13070B
|
GUIDE,SLIDE STOPPER |
13070-3706 |
|
13070C
|
GUIDE,SLIDE STOPPER |
13070-3707 |
|
13091
|
HOLDER,REVERSE LEVER |
13091-3756 |
|
13116
|
ROD-PUSH |
13116-3703 |
|
13168
|
LEVER,STEERING |
13168-3716 |
|
13234
|
SHAFT-COMP,JOINT |
13234-3708 |
|
13320
|
LEVER-ASSY,REVERSE |
13320-3704 |
|
46092
|
LEVER-GRIP,HANDLE STOPPER |
46092-3702 |
|
59266
|
JOINT-BALL |
59266-3707 |
|
92001
|
BOLT,BALL,6MM |
92001-3703 |
|
92009
|
SCREW,TAPPING,4X14 |
92009-3762 |
|
92028
|
BUSHING,BUA 12.5 13.5 19 |
92028-3746 |
|
92028A
|
BUSHING,BUA 26.2 41.8 3.5 |
92028-3747 |
|
92036
|
RING-SNAP |
92036-518 |
|
92043
|
PIN |
92043-3715 |
|
92043A
|
PIN,6X27.5 |
92043-3732 |
|
92122
|
ROLLER |
92122-3701 |
|
92143
|
COLLAR,8.2X14X11.2 |
92143-3724 |
|
92144
|
SPRING |
92144-3729 |
|
92144A
|
SPRING |
92144-3734 |
|
92150
|
BOLT,FLANGED,8X30 |
92150-3803 |
|
92200
|
WASHER,14.1X25X2 |
92200-3710 |
|
92200A
|
WASHER,8.5X25X1.5 |
92200-3717 |
|
|
|
|
