KAWASAKI
ULTRA LX
2010
Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA LX 2010 - Frame - Hull(G9F/GAF)
Frame
Hull(G9F/GAF)
No Part Part No Notes
311 NUT-HEX,6MM 311R0600
410 WASHER-PLAIN-SMALL,6MM 410S0600
410A WASHER-PLAIN-SMALL,8MM 410S0800
411 WASHER-PLAIN,5MM 411S0500
411A WASHER-PLAIN 411S1600
11051 BRACKET,BREATHER-BILGE 11051-3802
11052 BRACKET,RR DUCT 11052-3712
11056 BRACKET,WATER MUFFLER 11056-3722
11060 GASKET,U HOOK,RR 11060-3800
11060A GASKET,DRAIN PLUG 11060-3801
11061 GASKET,ECU COVER 11061-3749
11061A GASKET,STORAGE CASE COVER 11061-3753
11061B GASKET,BATTERY COVER 11061-3754
13227 HOUSING,DRAIN PLUG,F.BLACK 13227-3721-6Z
13270 PLATE 13270-3860
13271 PLATE 13271-3724
13280 HOLDER,EXHAUST VALVE 13280-3718
14073 DUCT,L=800 14073-3804
14073A DUCT 14073-3805
14073B DUCT,L=1000 14073-3836
14091 COVER,ECU 14091-3786
14091A COVER,BATTERY 14091-3809
14091B COVER,STORAGE CASE 14091-3819
27012 HOOK 27012-3797
27012A HOOK 27012-3816
27012B HOOK,BOW,F.BLACK 27012-3822-6Z
27012C HOOK,TOWING 27012-3860
32152 PIPE 32152-3749
32155 PIPE,COOLING 32155-3702
39031 CAP-END 39031-3704
59426 HULL-COMP,J.WHITE 59426-3969-8C
59437 STABILIZER,LH,F.BLACK 59437-3741-6Z
59437A STABILIZER,RH,F.BLACK 59437-3742-6Z
59446 COVER-JET PUMP 59446-3759
92009 SCREW,TAPPING,4X16 92009-3849
92015 NUT,20MM 92015-1589
92015A NUT,FLANGED,8MM 92015-1933
92022 WASHER,20.3X36X2.3 92022-1116
92037 CLAMP 92037-3738
92039 RIVET 92039-3741
92039A RIVET 92039-3755
92039B RIVET 92039-3775
92039C RIVET 92039-3785
92066A PLUG,RR,DRAIN,F.BLACK 92066-3783-6Z
92072 BAND,314X18 92072-3814
92072A BAND,L=608.22 92072-3884
92093 SEAL 92093-3720
92093A SEAL 92093-3783
92093B SEAL 92093-3784
92150 BOLT,SOCKET,6X18 92150-3775
92151 BOLT,SOCKET,M6,SHOULDER 92151-3746
92153 BOLT,SOCKET,8X55 92153-3746
92161 DAMPER 92161-3769
92200 WASHER 92200-3779
92210 NUT 92210-3707
