Frame
|
|
Hull/Engine Hood(JS440-A11/A12/A13)
|
|
| No |
Part |
Part No |
Notes |
|
1A
|
HULL-COMP,J.WHITE |
59426-3757-8C |
|
|
2
|
HULL,LH,EXTENSION,JET WHITE |
59251-3006-8C |
|
|
3
|
HULL,RH,EXTENSION,JET WHITE |
59251-3005-8C |
|
|
4
|
COVER,DASHBOARD |
14025-3706 |
|
|
5
|
RIVET,4MM |
92039-3703 |
|
|
6A
|
CAP |
11012-3721 |
|
|
7
|
SEAL-OIL |
92049-3709 |
|
|
8
|
HOOK |
27012-501 |
|
|
9
|
HOOK |
27012-502 |
|
|
10
|
SCREW,TAPPING |
92011-561 |
|
|
11
|
DAMPER,69X16T |
92075-3710 |
|
|
12
|
DAMPER,FUEL TANK |
92075-521 |
|
|
13
|
DAMPER,MUFFLER |
92075-522 |
|
|
14
|
GASKET,ENGINE HOOD |
92065-539 |
|
|
15
|
MAT |
59131-502 |
|
|
16
|
BUMPER |
59201-3691 |
|
|
17
|
DETENT |
59346-504 |
|
|
18
|
GRIP,HULL |
46075-3701 |
|
|
19A
|
NUT |
92015-3779 |
|
|
20A
|
MAT,DASHBOARD,LH |
53004-3727 |
|
|
21A
|
MAT,DASHBOARD COVER |
53004-3725 |
|
|
22
|
HOOD-COMP-ENGINE,JET WHITE |
59456-3001-8C |
|
|
23
|
BAND,HOOD |
92072-501 |
|
|
24
|
BOLT,6X30 |
92001-3022 |
|
|
25
|
WASHER,BAND |
92022-509 |
|
|
26
|
BRACKET,PLATE |
59086-501 |
|
|
27
|
GROMMET |
92071-056 |
|
|
28
|
LEVER |
13168-3701 |
|
|
29
|
DETENT |
59346-503 |
|
|
30
|
SCREW |
92011-562 |
|
|
31
|
HINGE |
53009-503 |
|
|
32A
|
MAT,DECK FIN,RH |
53004-3723 |
|
|
33A
|
MAT,DECK FIN,LH |
53004-3724 |
|
|
34A
|
MAT,DASHBOARD,RH |
53004-3726 |
|
|
35A
|
BUSHING |
92028-3734 |
|
|
|
|
