KAWASAKI
750 SXI
1996

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 750 SXI 1996 - Frame - Hull
Frame
Hull
No Part Part No Notes
120 BOLT-SOCKET,6X20 120R0620
221 SCREW-CSK-CROS,6X20 221R0620
311 NUT-HEX,6MM 311R0600
410 WASHER-PLAIN-SMALL,6MM 410S0600
411 WASHER-PLAIN,5MM 411S0500
11012 CAP,VIOLET 11012-3752-RE
11047 BRACKET,CONTROL KNOB 11047-3745
11047A BRACKET 11047-3754
11060 GASKET 11060-3722
13070 GUIDE,INTAKE 13070-3708
13091 HOLDER,BAND 13091-3764
13183 PLATE 13183-3787
14090 COVER,TANK CAP,J.S.VIOLET 14090-3707-23
39027 BUMPER-FRONT,VIOLET 39027-3726-RE
39028 BUMPER-REAR,LH,VIOLET 39028-3726-RE
39028A BUMPER-REAR,RH,VIOLET 39028-3727-RE
39145 TRIM-SEAL 39145-3731
53004 MAT 53004-3740
59426 HULL-COMP,J.WHITE 59426-3827-8C
59446 COVER-JET PUMP 59446-3715
59503A FENDER-BOAT,J.S.VIOLET 59503-3704-RE
92011 SCREW,TAPPING 92011-561
92015 NUT,CAP,5MM 92015-3802
92022 WASHER 92022-567
92038 KEY,TANK CAP 92038-3707
92057 CHAIN,COVER,L=100 92057-3704
92071 GROMMET 92071-3780
92072 BAND,L=145 92072-3768
92075 DAMPER 92075-3719
92093 SEAL,OSR70X82X7.5 92093-3704
92160 DAMPER 92160-3797
92200 WASHER 92200-3720
