KAWASAKI
800 SX-R
2010

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 800 SX-R 2010 - Frame - Hull
Frame
Hull
No Part Part No Notes
157 BOLT-WSP,5X18 157R0518
410 WASHER-PLAIN-SMALL,6MM 410S0600
11053 BRACKET 11053-3739
11060 GASKET,U HOOK,FR 11060-3799
11060A GASKET,DRAIN PLUG 11060-3801
13070 GUIDE,INTAKE,EBONY 13070-3732-H8
13227 HOUSING,DRAIN PLUG,F.BLACK 13227-3721-6Z
13270 PLATE 13270-3896
13271 PLATE 13271-3884
13271A PLATE 13271-3909
13280A HOLDER,TAIL PIPE CAP 13280-3742
13280B HOLDER 13280-3757
14091D COVER,NOSE,L.GREEN 14091-3773-777
27012 HOOK 27012-3797
39027 BUMPER-FRONT,F.BLACK 39027-3745-6Z
39028 BUMPER-REAR,LH,F.BLACK 39028-3753-6Z
39028A BUMPER-REAR,RH,F.BLACK 39028-3754-6Z
39031 CAP-END,TAIL PIPE 39031-3709
41077 ADAPTER 41077-3701
59071 JOINT 59071-3763
59426 HULL-COMP,G.BLACK 59426-3943-650
59446 COVER-JET PUMP 59446-3755
59503 FENDER-BOAT,F.BLACK 59503-3707-6Z
92009 SCREW,TAPPING,6X20 92009-3842
92009A SCREW,TAPPING,4X16 92009-3849
92009B SCREW,5X16 92009-3868
92015 NUT,FLANGED,8MM 92015-3709
92015A NUT,20MM 92015-3738
92039 RIVET 92039-3778
92039A RIVET 92039-3779
92039B RIVET 92039-3780
92039C RIVET 92039-3781
92066 PLUG,RR,DRAIN,F.BLACK 92066-3783-6Z
92072 BAND,L=188.85 92072-0105
92093 SEAL 92093-3720
92151 BOLT,SOCKET,M6,SHOULDER 92151-3746
92151A BOLT,SOCKET,6X20 92151-3774
92200 WASHER,5.9X16X1.5 92200-3714
