Frame
|
|
Hull
|
|
| No |
Part |
Part No |
Notes |
|
150
|
BOLT-WS,6X16 |
150R0616 |
|
|
156
|
BOLT-WP,6X20 |
156R0620 |
|
|
223
|
SCREW-PAN-WS-CROS,6X14 |
223R0614 |
|
|
311
|
NUT-HEX,6MM |
311R0600 |
|
|
11047
|
BRACKET,RR DUCT |
11047-3774 |
|
|
12022
|
VALVE-REED |
12022-3705 |
|
|
13070A
|
GUIDE,INTAKE |
13070-3721 |
|
|
13091
|
HOLDER,BAND |
13091-3764 |
|
|
13183
|
PLATE |
13183-3809 |
|
|
13270
|
PLATE |
13270-3731 |
|
|
13270A
|
PLATE |
13270-3785 |
|
|
14073
|
DUCT,FR |
14073-3741 |
|
|
14073B
|
DUCT,RR,INNER |
14073-3743 |
|
|
14073C
|
DUCT,FR |
14073-3746 |
|
|
14073D
|
DUCT,RR,UPPER |
14073-3756 |
|
|
27012
|
HOOK |
27012-3761 |
|
|
27012A
|
HOOK,BOW EYE |
27012-3766 |
|
|
27012B
|
HOOK |
27012-3776 |
|
|
27012C
|
HOOK |
27012-3789 |
|
|
39145
|
TRIM-SEAL,L=2170 |
39145-3741 |
|
|
59156
|
PIPE-TAIL |
59156-3711 |
|
|
59426A
|
HULL-COMP,J.WHITE |
59426-3845-8C |
59426A - HULL-COMP,J.WHITE
US*|*
|
|
59437
|
STABILIZER,LH,J.S.VIOLET |
59437-3706-RE |
|
|
59437B
|
STABILIZER,RH,J.S.VIOLET |
59437-3707-RE |
|
|
59446
|
COVER-JET PUMP |
59446-3729 |
|
|
92002
|
BOLT,6X16 |
92002-3728 |
|
|
92009
|
SCREW,6X15 |
92009-3830 |
|
|
92015
|
NUT,CAP,6MM |
92015-3755 |
|
|
92015A
|
NUT,6MM |
92015-3767 |
|
|
92015B
|
NUT |
92015-3815 |
|
|
92022
|
WASHER,6.5X20X1.5 |
92022-3710 |
|
|
92037
|
CLAMP |
92037-1173 |
|
|
92039
|
RIVET |
92039-3712 |
|
|
92039A
|
RIVET,4.8MM |
92039-3719 |
|
|
92039B
|
RIVET |
92039-3721 |
|
|
92039C
|
RIVET |
92039-3757 |
|
|
92066A
|
PLUG,RR,DRAIN |
92066-3724 |
|
|
92066B
|
PLUG,RR,DRAIN |
92066-3744 |
|
|
92071
|
GROMMET |
92071-3783 |
|
|
92072
|
BAND,BATTERY |
92072-3766 |
|
|
92072A
|
BAND,FUEL TANK |
92072-3772 |
|
|
92093
|
SEAL |
92093-3720 |
|
|
92143
|
COLLAR |
92143-3739 |
|
|
92150
|
BOLT,SOCKET,6X40 |
92150-3847 |
|
|
92160
|
DAMPER |
92160-3722 |
|
|
92160A
|
DAMPER |
92160-3872 |
|
|
92200
|
WASHER,6.5X16X1.0 |
92200-3712 |
|
|
|
|
