KAWASAKI
ULTRA 150
2004

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 150 2004 - Frame - Hull
Frame
Hull
No Part Part No Notes
311 NUT-HEX,6MM 311R0600
410 WASHER-PLAIN-SMALL,6MM 410S0600
11060 GASKET,U HOOK,RR 11060-3800
11060A GASKET,DRAIN PLUG 11060-3801
13227 HOUSING,DRAIN PLUG 13227-3711
13270 PLATE 13270-3860
13271 PLATE 13271-3724
13280 HOLDER,EXHAUST VALVE 13280-3718
27012 HOOK 27012-3797
27012A HOOK 27012-3816
27012B HOOK,BOW,F.BLACK 27012-3822-6Z
39031 CAP-END 39031-3704
59426A HULL-COMP,J.WHITE 59426-3925-8C
59437 STABILIZER,LH,F.BLACK 59437-3733-6Z
59437A STABILIZER,RH,F.BLACK 59437-3734-6Z
59446 COVER-JET PUMP 59446-3749
92009 SCREW,TAPPING,4X16 92009-3849
92015 NUT,FLANGED,8MM 92015-3709
92037 CLAMP 92037-3009
92066 PLUG,RR,DRAIN 92066-3744
92072 BAND,340X22 92072-3805
92072A BAND,248X18 92072-3829
92072B BAND,L=99 92072-3871
92093 SEAL 92093-3720
92150 BOLT,SOCKET,6X18 92150-3775
92150A BOLT,SOCKET,6X30 92150-3822
92151 BOLT,SOCKET,M6,SHOULDER 92151-3746
92152 COLLAR 92152-3715
92160 DAMPER 92160-3839
92160A DAMPER 92160-3840
92160B DAMPER 92160-3913
92161 DAMPER 92161-3704
92191 TUBE,39X51X70 92191-3856
92200 WASHER 92200-3779
