Frame
|
|
Hull
|
|
| No |
Part |
Part No |
Notes |
|
311
|
NUT-HEX,6MM |
311R0600 |
|
|
410
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
|
410A
|
WASHER-PLAIN-SMALL,8MM |
410S0800 |
|
|
411
|
WASHER-PLAIN,5MM |
411S0500 |
|
|
411A
|
WASHER-PLAIN |
411S1600 |
|
|
11051
|
BRACKET,BREATHER-BILGE |
11051-3802 |
|
|
11052
|
BRACKET,RR DUCT |
11052-3712 |
|
|
11054
|
BRACKET,WATER MUFFLER |
11054-3735 |
|
|
11060
|
GASKET,U HOOK,RR |
11060-3800 |
|
|
11060A
|
GASKET,DRAIN PLUG |
11060-3801 |
|
|
11061
|
GASKET,ECU COVER |
11061-3749 |
|
|
11061A
|
GASKET,STORAGE CASE COVER |
11061-3753 |
|
|
11061B
|
GASKET,BATTERY COVER |
11061-3754 |
|
|
13227
|
HOUSING,DRAIN PLUG,F.BLACK |
13227-3721-6Z |
|
|
13270
|
PLATE |
13270-3860 |
|
|
13271
|
PLATE |
13271-3724 |
|
|
13280
|
HOLDER,EXHAUST VALVE |
13280-3718 |
|
|
14073
|
DUCT |
14073-3804 |
|
|
14073A
|
DUCT |
14073-3805 |
|
|
14091
|
COVER,ECU |
14091-3786 |
|
|
14091A
|
COVER,BATTERY |
14091-3809 |
|
|
14091B
|
COVER,STORAGE CASE |
14091-3819 |
|
|
27012
|
HOOK |
27012-3797 |
|
|
27012A
|
HOOK |
27012-3816 |
|
|
27012B
|
HOOK,BOW,F.BLACK |
27012-3822-6Z |
|
|
27012C
|
HOOK,TOWING |
27012-3860 |
|
|
32152
|
PIPE |
32152-3748 |
|
|
39031
|
CAP-END |
39031-3704 |
|
|
59426B
|
HULL-COMP,S.RED |
59426-3965-H1 |
59426B - HULL-COMP,S.RED
US*|*
|
|
59426C
|
HULL-COMP,BLUE |
59426-3965-16F |
59426C - HULL-COMP,BLUE
US*|*
|
|
59426D
|
HULL-COMP,J.WHITE |
59426-3965-8C |
59426D - HULL-COMP,J.WHITE
US*|*
|
|
59437B
|
STABILIZER,LH,F.BLACK |
59437-3741-6Z |
|
|
59437C
|
STABILIZER,RH,F.BLACK |
59437-3742-6Z |
|
|
59446
|
COVER-JET PUMP |
59446-3759 |
|
|
92009
|
SCREW,TAPPING,4X16 |
92009-3849 |
|
|
92015
|
NUT,FLANGED,8MM |
92015-3709 |
|
|
92037
|
CLAMP |
92037-3738 |
|
|
92039
|
RIVET |
92039-3741 |
|
|
92039A
|
RIVET |
92039-3755 |
|
|
92039B
|
RIVET |
92039-3775 |
|
|
92039C
|
RIVET |
92039-3785 |
|
|
92066
|
PLUG |
92066-1306 |
|
|
92066A
|
PLUG,RR,DRAIN,F.BLACK |
92066-3783-6Z |
|
|
92072
|
BAND,314X18 |
92072-3814 |
|
|
92072A
|
BAND,L=535 |
92072-3881 |
|
|
92093
|
SEAL |
92093-3720 |
|
|
92093A
|
SEAL |
92093-3783 |
|
|
92150
|
BOLT,SOCKET,6X18 |
92150-3775 |
|
|
92151
|
BOLT,SOCKET,M6,SHOULDER |
92151-3746 |
|
|
92153
|
BOLT,SOCKET,8X55 |
92153-3746 |
|
|
92161
|
DAMPER |
92161-3769 |
|
|
92200
|
WASHER |
92200-3779 |
|
|
92210
|
NUT |
92210-3707 |
|
|
|
|
