Frame
|
Hull Fittings
|
|
No |
Part |
Part No |
Notes |
156
|
BOLT-WP,6X12 |
156R0612 |
|
11012
|
CAP,FIRE EXTINGUISHER |
11012-3766 |
|
11048
|
BRACKET,HATCH COVER |
11048-3776 |
|
11048A
|
BRACKET,HATCH COVER |
11048-3777 |
|
11048B
|
BRACKET,HATCH COVER LOCK |
11048-3778 |
|
11049
|
BRACKET,FUEL TAP |
11049-3714 |
|
13091
|
HOLDER,LOCK |
13091-3789 |
|
13270
|
PLATE,FIRE EXTINGUISHER |
13270-3729 |
|
14037
|
SCREEN,HANDLE COVER,RH |
14037-3705 |
|
14037A
|
SCREEN,HANDLE COVER,LH |
14037-3706 |
|
14090B
|
COVER,HATCH,P.C.GRAY |
14090-3747-JR |
|
14090G
|
COVER,HANDLE,P.C.GRAY |
14090-3748-JR |
|
14090K
|
COVER,STORAGE HINGE,BLACK |
14090-3763-6D |
|
14090N
|
COVER,CENTER STORAGE,P.C.GRAY |
14090-3774-JR |
|
23062
|
BRACKET-COMP,HATCH COVER |
23062-3711 |
|
23062A
|
BRACKET-COMP,STORAGE HINGE |
23062-3713 |
|
27012
|
HOOK,HATCH COVER LOCK |
27012-3803 |
|
27016B
|
LOCK-ASSY,HATCH COVER |
27016-3737 |
|
27016C
|
LOCK-ASSY,STORAGE COVER |
27016-3741 |
|
32099
|
CASE,FIRE EXTINGUISHER |
32099-3769 |
|
35011
|
STAY,MIRROR |
35011-3708 |
|
39012
|
CASE-STORAGE,FR |
39012-3713 |
|
39012A
|
CASE-STORAGE,TOOL CASE |
39012-3714 |
|
39145
|
TRIM-SEAL |
39145-3743 |
|
39145A
|
TRIM-SEAL,L=450 |
39145-3744 |
|
39156
|
PAD,KNEE,S.GRAY |
39156-3782-LG |
|
46075B
|
GRIP,TAIL,F.BLACK |
46075-3736-6Z |
|
46102
|
ROD,HATCH COVER STOPPER |
46102-3722 |
|
53044
|
TRIM,L=385 |
53044-1255 |
|
56001A
|
MIRROR-ASSY,LH,F.BLACK |
56001-3707-6Z |
|
56001C
|
MIRROR-ASSY,RH,F.BLACK |
56001-3708-6Z |
|
59071
|
JOINT |
59071-3743 |
|
92002
|
BOLT,6X25 |
92002-3714 |
|
92002A
|
BOLT,6X30 |
92002-3726 |
|
92002B
|
BOLT,6X16 |
92002-3728 |
|
92002C
|
BOLT,6X12 |
92002-3763 |
|
92009
|
SCREW,6X20 |
92009-3781 |
|
92009A
|
SCREW,5X16 |
92009-3789 |
|
92015
|
NUT,6MM |
92015-3767 |
|
92022A
|
WASHER,6.5X20X1.5 |
92022-3710 |
|
92022B
|
WASHER,6.2X20X2 |
92022-3714 |
|
92022C
|
WASHER |
92022-563 |
|
92033
|
RING-SNAP,E-TYPE,4MM |
92033-3722 |
|
92039
|
RIVET,4MM |
92039-3703 |
|
92039A
|
RIVET |
92039-3755 |
|
92066
|
PLUG |
92066-3752 |
|
92071
|
GROMMET |
92071-3808 |
|
92071A
|
GROMMET |
92071-3809 |
|
92143
|
COLLAR |
92143-3750 |
|
92143A
|
COLLAR |
92143-3753 |
|
92144
|
SPRING |
92144-3746 |
|
92150
|
BOLT,6X18 |
92150-3729 |
|
92160
|
DAMPER |
92160-3814 |
|
92160A
|
DAMPER |
92160-3821 |
|
92160C
|
DAMPER,TOOL CASE |
92160-3836 |
|
92160D
|
DAMPER |
92160-3839 |
|
92160E
|
DAMPER |
92160-3840 |
|
92160F
|
DAMPER,WATER MUFFLER |
92160-3841 |
|
92160G
|
DAMPER,FIRE EXTINGUISHER CASE |
92160-3858 |
|
92160H
|
DAMPER |
92160-3863 |
|
92160I
|
DAMPER,HANDLE COVER,FR |
92160-3893 |
|
92200
|
WASHER,5.9X16X1.5 |
92200-3714 |
|
92200A
|
WASHER,7.5X24X1.5 |
92200-3741 |
|
|
|
|
