KAWASAKI
900 STX
1997
Spare Part Category
Show me all the part categories of the model
KAWASAKI - 900 STX 1997 - Frame - Hull Fittings
Frame
Hull Fittings
No Part Part No Notes
110 BOLT,6X16 110R0616
150 BOLT-WS,6X14 150R0614
156 BOLT-WP,6X20 156R0620
311 NUT-HEX,5MM 311R0500
314 NUT-HEX-FINE,10MM 314R1000
410 WASHER-PLAIN-SMALL,6MM 410S0600
550 PIN-COTTER 550S2020
11012 CAP,FIRE EXTINGUISHER 11012-3766
11012A CAP,STORAGE,J.WHITE 11012-3797-8U
11047 BRACKET,SEAT SIDE LOCK 11047-3732
11047A BRACKET,HATCH COVER HINGE 11047-3788
11047B BRACKET,METER HOLDER 11047-3789
11048 BRACKET,METER COVER 11048-3741
11048 BRACKET,HATCH COVER 11048-3777
11050 BRACKET,HINGE 11050-3723
13091 HOLDER,STORAGE,J.WHITE 13091-3766-8U
13168 LEVER,HATCH LOCK 13168-3720
13183 PLATE,STORAGE 13183-3804
13183A PLATE,TAIL GRIP 13183-3805
13183 PLATE 13183-3754
13183A PLATE,HATCH LOCK 13183-3792
13183B PLATE,STORAGE LOCK 13183-3832
13270 PLATE,FIRE EXTINGUISHER 13270-3729
13270A PLATE 13270-3742
14041 COVER-COMP,HANDLE,F.RED 14041-3705-B1
14090 COVER,METER,F.RED 14090-3796-B1
14090 COVER,STORAGE,F.RED 14090-3723-B1
14090B COVER,STORAGE LOCK 14090-3729
14090C COVER,HINGE 14090-3793
14090D COVER,HATCH,F.RED 14090-3803-B1
14090G COVER,HATCH COVER,F.RED 14090-3805-B1
23062 BRACKET-COMP,HINGE 23062-3706
23062A BRACKET-COMP,HATCH COVER HINGE 23062-3707
27012 HOOK,HATCH COVER LOCK 27012-3769
27016 LOCK-ASSY,HATCH COVER CAP 27016-3738
27016A LOCK-ASSY,STORAGE COVER 27016-3739
32099 CASE,FIRE EXTINGUISHER 32099-3769
39012 CASE-STORAGE 39012-3718
39145 TRIM-SEAL,FRONT HATCH 39145-3736
39145A TRIM-SEAL,L=784 39145-3737
39156 PAD,HANDLE COVER,RH,RED 39156-3809-MJ
39156B PAD,HANDLE COVER,LH,RED 39156-3810-MJ
46075 GRIP,TAIL,F.RED 46075-3744-6L
46102 ROD,CONNECTION 46102-3724
46102A ROD,HATCH COVER HINGE 46102-3726
56001 MIRROR-ASSY,LH,F.RED 56001-3707-6L
56001B MIRROR-ASSY,RH,F.RED 56001-3708-6L
59071 JOINT 59071-3743
92002 BOLT,6X25 92002-3714
92002A BOLT,6X12 92002-3763
92002 BOLT,6X35 92002-3715
92002A BOLT,6X30 92002-3726
92002B BOLT,6X20 92002-3755
92002C BOLT,6X12 92002-3763
92009 SCREW,5X16 92009-3789
92009A SCREW,6X18 92009-3805
92009 SCREW,TAPPING,4X14 92009-3762
92009A SCREW,5X16 92009-3789
92009B SCREW,6X18 92009-3805
92015 NUT,6MM 92015-3767
92015 NUT,6MM 92015-3767
92022 WASHER,6.5X20X1.5 92022-3710
92022 WASHER,6.5X20X1.5 92022-3710
92022A WASHER,6.2X20X2 92022-3714
92033 RING-SNAP,E-TYPE,4MM 92033-3722
92036 RING-SNAP 92036-518
92039 RIVET,4MM 92039-3703
92039A RIVET 92039-3714
92039B RIVET 92039-3755
92039 RIVET,4MM 92039-3703
92043 PIN,6X27.5 92043-3732
92043A PIN,6X20 92043-3738
92055 RING-O,ID=131.6MM 92055-3732
92057 CHAIN,COVER,L=100 92057-3704
92071 GROMMET 92071-3716
92071A GROMMET 92071-3809
92143 COLLAR 92143-3750
92144 SPRING 92144-3731
92150 BOLT,6X18 92150-3729
92160G DAMPER 92160-3826
92160H DAMPER 92160-3895
92160I DAMPER 92160-3898
92160 DAMPER 92160-3814
92160A DAMPER 92160-3821
92160B DAMPER 92160-3899
92160 DAMPER 92160-3720
92160A DAMPER 92160-3775
92160B DAMPER,HANDLE COVER 92160-3811
92160C DAMPER,METER 92160-3816
92160D DAMPER 92160-3817
92160E DAMPER 92160-3824
92160F DAMPER,HANDLE COVER 92160-3825
92200 WASHER,5.9X16X1.5 92200-3714
