Frame
|
|
Hull Fittings
|
|
| No |
Part |
Part No |
Notes |
|
157
|
BOLT-WSP,6X16 |
157R0616 |
|
|
220
|
SCREW-PAN-CROS,6X14 |
220R0614 |
|
|
220A
|
SCREW-PAN-CROS,6X16 |
220R0616 |
|
|
411
|
WASHER-PLAIN,6MM |
411S0600 |
|
|
11046
|
BRACKET,STRAGE |
11046-3768 |
|
|
13183
|
PLATE |
13169-3714 |
|
|
13183A
|
PLATE,BATTERY |
13183-3751 |
|
|
14024
|
COVER,FRONT STORAGE,P.WHITE |
14024-3742-6F |
|
|
14073
|
DUCT,BLOWER |
14073-3719 |
|
|
27012
|
HOOK,WATER MUFFLER |
27012-3728 |
|
|
27012A
|
HOOK,BATTERY |
27012-3736 |
|
|
27012B
|
HOOK,STRAGE LOCK |
27012-3747 |
|
|
27016
|
LOCK-ASSY,STRAGE |
27016-3711 |
|
|
32102
|
PIPE |
32102-3704 |
|
|
39145
|
TRIM-SEAL |
39145-3724 |
|
|
53044
|
TRIM,REAR SIDE |
53044-3705 |
|
|
53044A
|
TRIM,FRONT SIDE |
53044-3706 |
|
|
92015
|
NUT,6MM |
92015-3792 |
|
|
92022
|
WASHER,6.5X20X1.5 |
92022-3710 |
|
|
92022A
|
WASHER,15X34X2.0 |
92022-3738 |
|
|
92033
|
RING-SNAP,2MM |
92033-3711 |
|
|
92043
|
PIN,3X31 |
92043-3724 |
|
|
92066
|
PLUG,PROTECTOR |
92066-3722 |
|
|
92072
|
BAND,SEAT |
92072-3737 |
|
|
92075
|
DAMPER |
92075-1737 |
|
|
92150
|
BOLT,6X30 |
92150-3766 |
|
|
92160
|
DAMPER,WATER MUFFLER |
92160-3705 |
|
|
92160A
|
DAMPER |
92160-3722 |
|
|
|
|
