Frame
|
Hull Fittings
|
|
No |
Part |
Part No |
Notes |
154
|
BOLT-WP-SMALL,8X30 |
154R0830 |
|
156
|
BOLT-WP,6X18 |
156R0618 |
|
156A
|
BOLT-WP,6X20 |
156R0620 |
|
156B
|
BOLT-WP,6X25 |
156R0625 |
|
220
|
SCREW-PAN-CROS,6X25 |
220R0625 |
|
224
|
SCREW-PAN-WP-CROS,5X14 |
224R0514 |
|
410
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
11012
|
CAP,SIDE BAND,J.WHITE |
11012-3756-8C |
|
11047
|
BRACKET,HANDLE FRAME |
11047-3735 |
|
11047A
|
BRACKET,HANDLE FRAME,UNDER,FR |
11047-3736 |
|
11047B
|
BRACKET,HANDLE FRAME,UNDER,RR |
11047-3737 |
|
11047C
|
BRACKET,SIDE BAND |
11047-3751 |
|
13183
|
PLATE,HINGE BRACKET |
13183-3781 |
|
13183A
|
PLATE,SIDE BAND |
13183-3796 |
|
14024
|
COVER,HANDLE TOWER,UPP,J.WHITE |
14024-3790-8C |
|
14024B
|
COVER,HANDLE TOWER,LWR,PURPLE |
14024-3791-JJ |
|
14024C
|
COVER,HATCH,J.WHITE |
14024-3792-8C |
|
14024D
|
COVER,REAR DUCT |
14024-3800 |
|
14024E
|
COVER,HANDLE TOWER,TOP,GRAY |
14024-3802-JH |
|
14024F
|
COVER,HANDLE TOWER,TOP,GRAY |
14024-3803-JH |
|
14037
|
SCREEN,HANDLE TOWER,TOP |
14037-3703 |
|
14037A
|
SCREEN,HANDLE TOWER,TOP |
14037-3704 |
|
16031
|
FLOAT,HANDLE,UPP |
16031-3806 |
|
23062
|
BRACKET-COMP,HATCH COVER |
23062-3703 |
|
27012
|
HOOK |
27012-501 |
|
27016
|
LOCK-ASSY,HATCH |
27016-3716 |
|
32160
|
FRAME-COMP,HANDLE |
32160-3701 |
|
39145
|
TRIM-SEAL,SEAT,L=1600 |
39145-3727 |
|
39145A
|
TRIM-SEAL,L=1058 |
39145-3730 |
|
53044
|
TRIM,L=250 |
53044-3709 |
|
53044A
|
TRIM,L=450 |
53044-3715 |
|
53044B
|
TRIM,L=550 |
53044-3716 |
|
92009
|
SCREW,TAPPING,4X14 |
92009-3755 |
|
92009A
|
SCREW,6X20 |
92009-3781 |
|
92009B
|
SCREW,5X16 |
92009-3789 |
|
92011
|
SCREW,TAPPING |
92011-561 |
|
92015
|
NUT |
92015-1700 |
|
92015A
|
NUT,POP,6MM |
92015-3762 |
|
92015B
|
NUT,5MM |
92015-3799 |
|
92022
|
WASHER,6.2X20X2 |
92022-3714 |
|
92027
|
COLLAR,6.2X10X10 |
92027-3705 |
|
92039
|
RIVET,4MM |
92039-3703 |
|
92071
|
GROMMET |
92071-3716 |
|
92072
|
BAND,STORAGE COVER |
92072-3756 |
|
92072B
|
BAND,SIDE,PINK |
92072-3758-PB |
|
92072C
|
BAND,SEAT STOPPER |
92072-3762 |
|
92160
|
DAMPER |
92160-3775 |
|
92200
|
WASHER,NYLON,5.2X12X1 |
92200-1011 |
|
|
|
|
