Frame
|
|
Hull Fittings
|
|
| No |
Part |
Part No |
Notes |
|
150
|
BOLT-WS,6X22 |
150R0622 |
|
|
410
|
WASHER-PLAIN-SMALL,6MM |
410S0600 |
|
|
11045
|
BRACKET,WATER MUFFLER |
11045-3763 |
|
|
13183
|
PLATE,SEAT,FR |
13183-3721 |
|
|
18001
|
MUFFLER,TAIL |
18001-3719 |
|
|
32046
|
BRACKET-SEAT,FR |
32046-3704 |
|
|
32046A
|
BRACKET-SEAT,CNT,LH |
32046-3705 |
|
|
32046B
|
BRACKET-SEAT,CNT,RH |
32046-3706 |
|
|
32097
|
CASE-BATTERY |
32097-3702 |
|
|
49107
|
COVER-EXHAUST PIPE |
49107-3703 |
|
|
92011
|
SCREW,TAPPING |
92011-561 |
|
|
92015
|
NUT |
92015-3779 |
|
|
92028
|
BUSHING |
92028-3734 |
|
|
92039
|
RIVET |
92039-3002 |
|
|
92039A
|
RIVET |
92039-3714 |
|
|
92039B
|
RIVET |
92039-3730 |
|
|
92072
|
BAND,BATTERY,L=366 |
92072-3706 |
|
|
92072A
|
BAND,L=544 |
92072-3709 |
|
|
92072B
|
BAND,L=479 |
92072-3712 |
|
|
92075
|
DAMPER,BATTERY |
92075-3714 |
|
|
92075A
|
DAMPER,FUEL TANK,LH |
92075-3727 |
|
|
92075B
|
DAMPER,FUEL TANK,RH |
92075-3729 |
|
|
92075C
|
DAMPER,FUEL TANK |
92075-3738 |
|
|
92075D
|
DAMPER,FIRE EXTINGUISHER |
92075-3750 |
|
|
92075E
|
DAMPER,FUEL TANK |
92075-3751 |
|
|
92075F
|
DAMPER,WATER MUFFLER,LH |
92075-3761 |
|
|
92075G
|
DAMPER,WATER MUFFLER,RH |
92075-3762 |
|
|
92075H
|
DAMPER,MUFFLER |
92075-522 |
|
|
|
|
