KAWASAKI - STX-12F 2006 - Frame - Hull Middle Fittings

Frame
Hull Middle Fittings
No	Part	Part No	Notes
11051	BRACKET,CROSSMEMBER	11051-3782
11051A	BRACKET	11051-3811
13107	SHAFT	13107-3761
13107A	SHAFT	13107-3769
14037	SCREEN,METER,F.S.BLACK	14037-3709-378
14091A	COVER,SIDE,LH,F.S.BLACK	14091-3708-378
14091D	COVER,SIDE,RH,F.S.BLACK	14091-3709-378
14091F	COVER,CENTER STORAGE,J.WHITE	14091-3710-8C
14091H	COVER,HANDLE,F.S.BLACK	14091-3770-378
27017	LOCK,CENTER STORAGE	27017-3725
39012	CASE-STORAGE	39012-3735
39043	CROSSMEMBER-COMP	39043-3703
53044	TRIM,L=180	53044-3755
92002	BOLT,6X25	92002-3714
92002A	BOLT,6X30	92002-3726
92002B	BOLT,6X12	92002-3763
92009	SCREW,TAPPING,5X20	92009-3716
92015	NUT,LOCK,5MM	92015-3798
92015A	NUT,CLIP,5MM	92015-3830
92022	WASHER,5X16X1.5	92022-3041
92022A	WASHER,6.5X20X1.5	92022-3710
92066	PLUG	92066-3773
92145	SPRING	92145-3711
92150	BOLT,5X16	92150-3778
92153	BOLT,5MM	92153-3703
92160	DAMPER	92160-3933
92161	DAMPER	92161-3756
92161A	DAMPER	92161-3757
