KAWASAKI
550 SX
1995

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 550 SX 1995 - Frame - Ignition System
Frame
Ignition System
No Part Part No Notes
220 SCREW-PAN-CROS,6X12 220B0612
220A SCREW-PAN-CROS,6X16 220B0616
220B SCREW-PAN-CROS,6X20,WHITE 220B0620
311 NUT-HEX,6MM 311R0600
410 WASHER-PLAIN-SMALL,6MM 410B0600
410A WASHER-PLAIN-SMALL,10MM 410B1000
410B WASHER-PLAIN-SMALL,6MM 410S0600
670 O RING,16MM 670B2016
11009 GASKET,ELECTRIC CASE 11009-3781
11012 CAP 11012-3005
21066A REGULATOR-VOLTAGE 21066-3710
21119A IGNITER 21119-3723
21130 CAP-SPARK PLUG 21130-3706
21177A CONTROLLER 21177-3703
26004 FUSE-ASSY 26004-3711
27010A SWITCH,STARTER RELAY 27010-3724
59071 JOINT 59071-3001
59221 CONNECTOR-CORD 59221-505
59416 CASE-ELECTRIC,RR 59416-3003-YR
59416A CASE-ELECTRIC,FR 59416-3004-YR
92002 BOLT,6X25 92002-3714
92022 WASHER 92022-3035
92026 SPACER 92026-3703
92037 CLAMP 92037-1173
92037A CLAMP,L=100 92037-3736
92059 TUBE,7.5X10X250 92059-2153
92059A TUBE,7.5X10X130 92059-2154
92070 PLUG-SPARK,BR8ES(NGK) 92070-2078
92071 GROMMET 92071-3004
92071A GROMMET 92071-517
92071B GROMMET 92071-527
92071C GROMMET 92071-529
92150 BOLT,6X80 92150-3761
