KAWASAKI
ULTRA 150
2001

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 150 2001 - Frame - Ignition System
Frame
Ignition System
No Part Part No Notes
311 NUT-HEX,6MM 311R0600
410 WASHER-PLAIN-SMALL,10MM 410B1000
410A WASHER-PLAIN-SMALL,6MM 410S0600
11012 CAP 11012-3005
11060 GASKET,ELECTRIC CASE 11060-3805
13091 HOLDER 13091-3785
13271 PLATE 13271-3707
13280 HOLDER 13280-3706
13280A HOLDER 13280-3711
13280B HOLDER 13280-3712
21066 REGULATOR-VOLTAGE 21066-3715
21119 IGNITER 21119-3757
21121 COIL-IGNITION,#1 21121-3714
21121A COIL-IGNITION,#2 21121-3715
21121B COIL-IGNITION,#3 21121-3716
21130 CAP-SPARK PLUG 21130-3706
21176 SENSOR,INTAKE AIR TEMP 21176-3730
21176A SENSOR,COOLING WATER TEMP 21176-3731
26011 WIRE-LEAD 26011-3857
26011A WIRE-LEAD 26011-3871
26011B WIRE-LEAD 26011-3880
27010 SWITCH 27010-3757
59416 CASE-ELECTRIC 59416-3747
59416A CASE-ELECTRIC 59416-3748
59416B CASE-ELECTRIC,UPP 59416-3749
59416C CASE-ELECTRIC,LWR 59416-3750
92009 SCREW,TAPPING,6X25 92009-1640
92009A SCREW,6X14 92009-3845
92009B SCREW,6X18 92009-3846
92026 SPACER 92026-3703
92037 CLAMP 92037-1173
92037A CLAMP,HOSE 92037-1603
92066 PLUG 92066-1347
92070 PLUG-SPARK,BR9ES(NGK),SOLID 92070-1157
92071 GROMMET 92071-3004
92071A GROMMET 92071-527
92093 SEAL 92093-3754
92093A SEAL 92093-3756
92145 SPRING 92145-3710
92170 CLAMP 92170-3765
92191 TUBE,8X10X690 92191-3847
92191A TUBE,8X10X570 92191-3848
92191B TUBE,8X10X500 92191-3849
