KAWASAKI
750 SXI
1996

Spare Part Category
Show me all the part categories of the model
KAWASAKI - 750 SXI 1996 - Frame - Jet Pump
Frame
Jet Pump
No Part Part No Notes
120 BOLT-SOCKET 120R0616
120A BOLT-SOCKET,6X20 120R0620
410 WASHER-PLAIN-SMALL,6MM 410S0600
410A WASHER-PLAIN-SMALL,8MM 410S0800
11012 CAP,JET PUMP 11012-3712
13107 SHAFT,JET PUMP 13107-3721
39145 TRIM-SEAL 39145-3735
52014 ELBOW 52014-3708
59136 NOZZLE-PUMP 59136-3730
59255 IMPELLER-COMP 59255-3706
59266 JOINT-BALL 59266-3707
59366 GRATE 59366-3707
59476 NOZZLE-STRG 59476-3713
59496 VANE-GUIDE 59496-3726
92001 BOLT,SOCKET,6X11 92001-3701
92002 BOLT,6X40 92002-3716
92002A BOLT,6X16 92002-3728
92002B BOLT,SOCKET,8X20 92002-3771
92022 WASHER,8.4X23X2.5 92022-3744
92022A WASHER 92022-567
92026 SPACER,JET PUMP 92026-3708
92028 BUSHING,17X25X15 92028-3717
92045 BEARING-BALL,#63032RD 92045-3706
92049 SEAL-OIL,TBY25X47X6 92049-3714
92055 RING-O,13X1.9 92055-1021
92055A RING-O 92055-3706
92093 SEAL,JET PUMP 92093-3739
92143 COLLAR,17.4X25.4X53 92143-3708
