KAWASAKI
STS
1996

Spare Part Category
Show me all the part categories of the model
KAWASAKI - STS 1996 - Frame - Jet Pump
Frame
Jet Pump
No Part Part No Notes
410 WASHER-PLAIN-SMALL,6MM 410S0600
410A WASHER-PLAIN-SMALL,8MM 410S0800
411 WASHER-PLAIN,6MM 411S0600
11012 CAP,JET PUMP 11012-3712
13107 SHAFT,JET PUMP 13107-3721
39145 TRIM-SEAL 39145-3732
52014 ELBOW 52014-3708
59136 NOZZLE-PUMP 59136-3722
59255A IMPELLER-COMP 59255-3710
59266 JOINT-BALL 59266-3707
59366 GRATE 59366-3710
59476 NOZZLE-STRG 59476-3727
59477 BUCKET-REVERSE 59477-3704
59496 VANE-GUIDE 59496-3703
92002 BOLT,6X30 92002-3726
92002A BOLT,6X16 92002-3728
92002B BOLT,SOCKET,8X20 92002-3771
92022B WASHER 92022-567
92025 SHIM,T=0.5MM 92025-3702
92025A SHIM,T=1.5MM 92025-3708
92028 BUSHING,17X25X15 92028-3717
92028A BUSHING 92028-3740
92045 BEARING-BALL,#63032RD 92045-3706
92049 SEAL-OIL,TBY25X47X6 92049-3714
92055 RING-O,13X1.9 92055-1021
92055A RING-O 92055-3706
92062 NOZZLE 92062-3717
92093 SEAL,JET PUMP 92093-3739
92143 COLLAR,17.4X25.4X53 92143-3708
92150 BOLT,SOCKET,6X10 92150-3759
92150A BOLT,SOCKET,6X18 92150-3795
92150B BOLT 92150-3808
92160 DAMPER 92160-3738
