KAWASAKI
ULTRA 150
2000

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 150 2000 - Frame - Jet Pump
Frame
Jet Pump
No Part Part No Notes
314 NUT-HEX-FINE,10MM 314R1000
410 WASHER-PLAIN-SMALL,6MM 410S0600
411 WASHER-PLAIN,10MM 411S1000
670 O RING,12MM 670B2012
11050 BRACKET 11050-3758
11065 CAP 11065-3705
13107 SHAFT 13107-3773
13270 PLATE 13270-3905
32152 PIPE 32152-3742
32152A PIPE 32152-3743
32152B PIPE 32152-3744
32152C PIPE 32152-3745
32152D PIPE 32152-3751
39112 RODEND-TIE 39112-3703
39145 TRIM-SEAL 39145-3758
39145A TRIM-SEAL 39145-3766
43058 RING,TILT 43058-3731
59071 JOINT,CABLE 59071-3760
59136 NOZZLE-PUMP 59136-3742
59255 IMPELLER-COMP 59255-3715
59336 CASE-PUMP 59336-3713
59366 GRATE 59366-3718
59476 NOZZLE-STRG 59476-3738
59496 VANE-GUIDE 59496-3735
92002 BOLT,6X25 92002-3714
92002A BOLT,6X40 92002-3716
92004 STUD,10X35 92004-3732
92009 SCREW 92009-3780
92022 WASHER,PLAIN 92022-3026
92028 BUSHING 92028-3773
92033 RING-SNAP 92033-3730
92043 PIN,12X12 92043-3745
92043A PIN,10X12 92043-3747
92045 BEARING-BALL,62022RD 92045-3721
92045A BEARING-BALL 92045-3730
92049 SEAL-OIL,HVAJ25X45X7 92049-3726
92049A SEAL-OIL,SCJ25X45X7 92049-3727
92055 RING-O,OIL FILTER 92055-1011
92055A RING-O,52.6X2.4 92055-1520
92066 PLUG,PT1/4X8.9 92066-3765
92093 SEAL 92093-3749
92139 BUSHING 92139-3701
92150 BOLT,SOCKET,6X18 92150-3775
92150A BOLT,8X35 92150-3792
92151 BOLT 92151-3705
92151A BOLT,10X110 92151-3733
92151B BOLT,8MM 92151-3735
92151C BOLT,8X32 92151-3752
92151D BOLT,SOCKET,6X20 92151-3774
92152 COLLAR,8.2X11.8X15 92152-3703
92160 DAMPER 92160-3932
92180 SHIM,T=0.5 92180-3705
92210 NUT,LOCK,8MM 92210-3742
