KAWASAKI
ULTRA 250X
2008

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 250X 2008 - Frame - Jet Pump
Frame
Jet Pump
No Part Part No Notes
410 W-PLAIN-S,5MM 410S0500
410A WASHER-PLAIN-SMALL,6MM 410S0600
610 ROLLER,4X8 610A0408
11012 CAP 11012-3786
11054 BRACKET,JET PUMP 11054-3709
11065 CAP 11065-3733
13107 SHAFT,JET PUMP 13107-3788
14091 COVER,COOLING TUBE 14091-3808
14091A COVER,VANE GUIDE 14091-3817
39112 RODEND-TIE 39112-3703
39145 TRIM-SEAL,VANE GUIDE 39145-3799
52014 ELBOW 52014-3711
52014A ELBOW 52014-3727
59136 NOZZLE-PUMP 59136-3764
59255 IMPELLER-COMP 59255-3735
59266 JOINT-BALL 59266-3710
59366 GRATE 59366-3723
59476 NOZZLE-STRG 59476-3744
59477 BUCKET-REVERSE 59477-3712
59496 VANE-GUIDE 59496-3757
92002 BOLT,6X25 92002-3714
92002A BOLT,6X30 92002-3726
92009 SCREW,6X20 92009-3848
92022 WASHER,PLAIN 92022-3026
92022A WASHER,8.4X23X2.5 92022-3744
92022B WASHER 92022-567
92028 BUSHING 92028-3773
92033 RING-SNAP 92033-3730
92045 BEARING-BALL,6303R-6 92045-3740
92045A BEARING-BALL,62/22 2RS 92045-3743
92049 SEAL-OIL 92049-3739
92055 RING-O,13.0X1.9 92055-1011
92055A RING-O,27.7X1.9 92055-1272
92055B RING-O 92055-3741
92055C RING-O 92055-3744
92055D RING-O,70.2X74.0X1.90 92055-3765
92093 SEAL 92093-3749
92139 BUSHING 92139-3701
92150 BOLT,SOCKET,6X18 92150-3775
92150A BOLT,8X35 92150-3792
92150B BOLT,FLANGED,8X30 92150-3803
92151 BOLT,10X30 92151-3706
92152 COLLAR,8.2X11.8X15 92152-3703
92153 BOLT,SOCKET,5X30 92153-3742
92210 NUT,6MM 92210-3789
