KAWASAKI
ULTRA 300LX
2013

Spare Part Category
Show me all the part categories of the model
KAWASAKI - ULTRA 300LX 2013 - Frame - Jet Pump
Frame
Jet Pump
No Part Part No Notes
410 W-PLAIN-S,5MM 410S0500
410A WASHER-PLAIN-SMALL,6MM 410S0600
410B WASHER-PLAIN-SMALL,8MM 410S0800
610 ROLLER,4X8 610A0408
11055 BRACKET,PUMP 11055-3710
11065 CAP 11065-0826
11065A CAP 11065-3733
13107 SHAFT 13107-0764
13107A SHAFT 13107-3804
13234 SHAFT-COMP 13234-3712
14091 COVER,COOLING TUBE 14091-3808
14091A COVER,VANE GUIDE 14091-3817
39112 RODEND-TIE 39112-3703
39112A RODEND-TIE 39112-3707
39145 TRIM-SEAL 39145-3809
43058 RING 43058-3735
52014 ELBOW 52014-3711
52014A ELBOW 52014-3727
59136 NOZZLE-PUMP 59136-3768
59255 IMPELLER-COMP 59255-3740
59266 JOINT-BALL 59266-3710
59366 GRATE 59366-3724
59476 NOZZLE-STRG 59476-0063
59477 BUCKET-REVERSE 59477-3713
59496 VANE-GUIDE 59496-3767
92002 BOLT,6X25 92002-3714
92002A BOLT,6X30 92002-3726
92009 SCREW,6X20 92009-3848
92015 NUT,18MM 92015-1512
92022 WASHER,8.4X23X2.5 92022-3744
92022A WASHER 92022-567
92033 RING-SNAP 92033-3730
92045 BEARING-BALL,6303R-6 92045-3744
92045A BEARING-BALL,62/22 2RS 92045-3745
92049 SEAL-OIL 92049-3739
92055 RING-O,49.7X2.4 92055-0183
92055A RING-O,12X1.5 92055-025
92055B RING-O,27.7X1.9 92055-1272
92055C RING-O 92055-3741
92055D RING-O 92055-3744
92055E RING-O,66.5X2.0 92055-3784
92093 SEAL 92093-3749
92139 BUSHING 92139-0767
92139A BUSHING 92139-3720
92150 BOLT,SOCKET,6X18 92150-3775
92150A BOLT,8X35 92150-3792
92150B BOLT,FLANGED,8X30 92150-3803
92151 BOLT,10X30 92151-3706
92152 COLLAR,8.2X11.8X13.5 92152-1694
92152A COLLAR,8.2X11.8X15 92152-3703
92153 BOLT,SOCKET,5X30 92153-3742
92154 BOLT,FLANGED,8X25 92154-3705
92154A BOLT,BALL,8X30 92154-3706
92154B BOLT,SOCKET,8X15 92154-3707
92154C BOLT,BALL,6MM 92154-3710
92154D BOLT,SOCKET,8X18 92154-3711
92200 WASHER,8.0X22.0X1.5 92200-0174
92210 NUT,6MM 92210-3789
