KAWASAKI
JS550
1983

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JS550 1983 - Exhaust - MUFFLER
Exhaust
MUFFLER
No Part Part No Notes
1 GASKET,EXHAUST PIPE 11009-3051
2 PIPE-EXHAUST FRONT 18049-3008-YR
3 GASKET 11060-3730
4 JOINT,HOSE 92005-3001
5 BOLT,6X60 110R0660
6 BOLT,6X80 110R0680
7 WASHER 410S0600
8 STUD,8X35 172R0835
9 NUT,8 M/M 311M0800
10 WASHER 410S0800
11 WASHER SPRING 8MM 461S0800
12 TUBE,9X16X80 92059-3039
13 CLAMP,HOSE 92037-504
14 PIPE-COMP-EXHAUST 49062-3001-YR
15 JOINT,HOSE 92005-3001
16 TUBE,9X16X230 92059-3040
17 CLAMP,HOSE 92037-504
18 CLAMP,HOSE 92037-504
19 MUFFLER 18001-3008
20 TUBE,MUFFLER 92059-3041
21 CLAMP 92037-541
22 PIPE-RESNTR. CONNECTR 59151-528
23 TUBE 92059-542
24 TUBE 92059-543
25 CLAMP 92037-541
26 CLAMP,HOSE 92037-506
27 CLAMP 92037-509
28 MUFFLER-COMP,WATERBOX 49070-3714
29 HOSE 92059-528
30 BAND 92072-511
31 PIPE,TAIL 59156-506
32 RIVET 59281-506
33 HOSE,TAIL 92059-549
34 CLAMP 92037-545
35 SCREW,6X45 92009-3747
36 WASHER 92095-513
37 NUT,6M/M 92015-532
38 NUT,6M/M 311R0600
