KAWASAKI
JET SKIΒ® ULTRAΒ® 310X
2016

Spare Part Category
Show me all the part categories of the model
KAWASAKI - JET SKIΒ® ULTRAΒ® 310X 2016 - Engine/Transmission - Oil Pump
Engine/Transmission
Oil Pump
No Part Part No Notes
132 BOLT-FLANGED-SMALL,6X20 132BD0620
551 PIN-DOWEL 551R0408
670 O RING,14MM 670D2014
12046 SPROCKET,23T 12046-3708
13107 SHAFT 13107-0730
13272 PLATE,RH 13272-1563
13272C PLATE,LH 13272-1798
14091 COVER 14091-3767
16097 FILTER-ASSY-OIL 16097-0007
16097A FILTER-ASSY-OIL 16097-3702
16130 VALVE-ASSY-RELIEF 16130-3701
16142 COVER-PUMP 16142-3703
16154 ROTOR-PUMP 16154-1124
16160 BODY,OIL PUMP 16160-0705
32154 PIPE,OIL LEVEL 32154-3721
52005 GAUGE,OIL LEVEL 52005-0729
92002 BOLT,6X12 92002-3763
92042 PIN,DOWEL,4X15.8 92042-014
92043 PIN,11.5X14X14 92043-1279
92055 RING-O,9.8X2.4 92055-1150
92055A RING-O,19.8X1.9 92055-1332
92055B RING-O 92055-3764
92057 CHAIN,OIL PUMP,98XRH2010-52L 92057-3713
92066 PLUG,PT1/2X12.5 92066-0002
92154 BOLT,SOCKET,6X16 92154-3709
92200 WASHER,6X20X3.2 92200-0120
