KAWASAKI
TS
1989

Spare Part Category
Show me all the part categories of the model
KAWASAKI - TS 1989 - Electrical - Starter Motor
Electrical
Starter Motor
No Part Part No Notes
311 NUT-HEX,6MM 311R0600
13101 GEAR-ASSY 13101-3701
21039 BRUSH,CARBON 21039-3702
21040 SPRING-BRUSH 21040-1003
21163 STARTER-ELECTRIC 21163-3702
92002 BOLT,6X25 92002-3714
92002A BOLT 92002-3744
92015 NUT,6MM 92015-3710
92022 WASHER,9.1X18X0.2 21025-011
92022A WASHER,9.1X18X0.8 92022-1132
92022B WASHER,6MM 92022-3711
92022C WASHER,SPRING,5MM 92022-3712
92055 RING-O,64MM 92055-1086
92055A RING-O 92055-1276
92055B RING-O,4.5X2.0 92055-1370
